Home > Electrical & Electronics > Connector & Terminals > Wire to Wire Connector > (Free Sample)SMA Female Gold Coaxial Connector for Mounting
US$ 5,000 - 1,000,000
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
linkeson, linkeson
Model Number:
SMA female gold coaxial connector for mounting
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
3pin Microphone XLR Female ConnectorUS$ 1 - 2MOQ: 1 Piece -
RF Coaxial SMA Female Flange Mount ConnectorUS$ 0.8 - 1.8MOQ: 1 Piece
-
RF Coaxial F Type Female Connector for PCBUS$ 0.1 - 0.6MOQ: 100 Pieces
-
SSMB Female Connector for RG316 LMR100 Flexible CableUS$ 0.35 - 0.5MOQ: 1 Piece
-
RF Coaxial SMB PCB Mount Female ConnectorUS$ 0.35 - 0.5MOQ: 1 Piece
Place of Origin
Jiangsu, China
Brand Name
linkeson, linkeson
Model Number
SMA female gold coaxial connector for mounting
Type
SMA
Application
Other, RF,automotive,power,microwave,audio and video,antenna,WIFI, RF,automotive,power,microwave,audio and video,antenna,WIFI
Gender
Other, Female, female
Specifications
1.SMA female gold connector for mount2.MIL-C-39012
3.IEC-169-15
4.CECC-22110
5.ISO9001 2008 Standard,short delivery time
SMA female gold coaxial connector for mounting
Series SMA are very popular thread coupling miniature coaxial connectors.Which have the excellent performances of high reliability,high mechanical strength,high durability,and optimum electrical properties, are widely used to connect RF coaxial cables for mobile communication equipments and electronic communication instruments.they are widely use in electronic instrument,communication equipment,internet system,microwave testing,cable assembly and metal plate.
| Key Performance | ||||||
| Temperature range | -65~+165 | Insulation resistance | ≥5000MΩ | |||
| Characteristic impedance | 50Ω | Dielectric Withstanding voltage | 1000V(r ms) | |||
| Frequency range | With flexible cable | 0~12.4GHz | Contact resistance | Center conductor | ≤3mΩ | |
| With semi-rigid/flexible cable | 0~18GHz | Outer conductor | ≤2mΩ | |||
| VSWR | With flexible cable | ≤1.15+0.02F | Durability | 500 Cycles | ||
| With semi-rigid/flexible cable | ≤1.05+0.02F | |||||
| Material And Plating | ||||||
| Body | Brass , gold plated or stainless steel passivated | |||||
| Male center contacts | Brass , gold plated | |||||
| Female center contacts | Beryllium copper , gold plated | |||||
| Insulators | PTFE | |||||
| Gaskets | Silicon rubber | |||||
| Crimp ferrules | Copper alloy , gold or nickel plated | |||||
