UNS R60702 Zirconium Coiled Pipe

Specifications

UNS R60702 Zirconium Coiled Pipe

Specifications:
Zirconium Coil Pipes
Zirconium Coil Pipes Meeting ASME SB-523/SB658;GB/T 26283-2010
Grades: R60702/4/5
ISO9001:2008 Certified
Zirconium Coil Pipes
Zirconium Pipes and Tubes Meeting ASTM B523/B523M-07,ASME SB-523; ASTM B658,ASME SB658;GB/T 26283-2010 Grades: R60702/4/5
ISO9001:2008 Certified.
 Zirconium Pipes and Tubes  are widedly used in chemical columns,vessels and reactors,heat exchangers,Porous Filters,Anode Basket and electrode in plating solution and etching agent.
Zirconium Coil Pipes: Used in FRP vessels,for steam heating and circulating water cooling.

As a new corrosion-resistant metal, Zirconium is playing a more and more important role in chemical industry.Our Zirconium Coil Pipes are being widely used by fertilizer and pesticide producers for its unique and excellent anticorrosion performance.We apply state-of-the-art techniques in the fabrication of Zr coil pipes to eliminate customers' concern about corrosion.Compared with conventional reactors, FRP reactors equipped with zirconium coil pipes enjoyed numerous advantages.If you have interest in this field,please contact us for more information.
Product Properties:
Good heat-conductivity, short heating and cooling time, high efficiency.
Product Advantages:
Long equipment life; low maintenance cost; saving downtime; Light, easy to install; high security; cost-effective.

Zirconium Pipes and Tubes  Size:
19 (OD) x 1.0/1.5/2.0mm(WT)
25(OD) x 1.0/1.5/2.0mm( WT )
30(OD) x 2.0/3.0mm( WT )
38 (OD) x 2.0/2.5/3.0mm WT )
45 (OD) x 2.5/3.0mm( WT )
57 (OD) x 2.5/3.0mm( WT )
70(OD) x 7.0mm( WT )
76 (OD) x 3.5/4.0mm( WT )
Other Products:
Zirconium ingot, billet,bloom, slab
Zirconium plate, sheet, foil, strip, ribbon
Zirconium round rod, rectangular bar
Zirconium wire
Zirconium tube, pipe
Zirconium forgings and castings

Company Introduction

About Us

Nanjing Maici Titanium Industry Co., Ltd established in 2004 with the fixed assets of 80 million yuan and more than 120nos of existing staff. Maici is located in Nanjing Jiangning Airport Industrial Park, covers an area of 18,000 square meters.

Maici is a private joint-stock high-tech enterprise, specialized in design, manufacture and installation oftitanium, nickel, zirconium, tantalum and high grade stainless steel and other special materials pressure pipelines, chemical equipment and non-standard pipe fittings including which special material pressure pipeline is in the domestic leading level from the processing capacity to the marketing scale
