Product Details
Brand Name | HUIZE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
350kgs,1.6m Long-lived hydraulic drum lifter and tilter
Product description 350kgs,1.6m Long-lived hydraulic drum lifter and tilter
1. imported control system
2. Be applicable to all kinds of metal, plastic barrels, opening barrels, small barrels
3. Can clip,lift,flip and revolve 180 degree to pour material.
1 | Features | ||
1.1 | Name |
| 350kgs,1.6m Long-lived hydraulic drum lifter and tilter uk |
1.2 | Model |
| COT -500 |
1.3 | Mast series |
| Single |
1.4 | Dynamic form |
| Battery |
1.6 | Braking form |
| Electromagnetic brake |
1.7 | Load capacity | Q(Kg) | 350 |
1.8 | Hydraulic cylinder |
| Single |
1.9 | Color |
| Red yellow blue gray |
2 | Size | ||
2.1 | Rising height | mm | 2500 |
2.2 | Drum clip minimum height | mm | 540 |
2.3 | Overall length | mm | 2000 |
2.4 | Overall width | mm | 1000 |
2.5 | Overall height | mm | 2000 |
2.6 | Front wheel size | mm | Φ80*70 |
2.7 | Driving wheel size | mm | φ250*80 |
2.8 | Balance wheel size | mm | φ125*50 |
2.9 | Drum size | φf | φ580*900 |
2.10 | Drums flip angle |
| 360° |
2.11 | Channel width | Ast(mm) | 1100 |
2.12 | Minimum channel width truck turning around | Ast(mm) | 2500 |
2.13 | Radius of turning circle | Wa(mm) | 2100 |
3 | Performance | ||
3.1 | Travel speed(loaded/unloaded) | km/h | 4/6 |
3.2 | Rising speed(loaded/unloaded) | mm/s | 90/105 |
3.3 | Falling speed(loaded/unloaded) | mm/s | 110/105 |
3.4 | Climbing gradient(loaded/unloaded) | % | 5/8 |
3.5 | Braking length(loaded/unloaded) | mm | 500/350 |
tacker
Certifications 350kgs,1.6m Long-lived hydraulic drum lifter and tilter
1.6m new Hydraulic electric pallet s
After-sales service 350kgs,1.6m Long-lived hydraulic drum lifter and tilter
1.End users:We can provide video to tell you how to maintain and repair;
Provide accessories for free in one year;
One year later ,provide these accessories at cost and charge
express fee.
2.Retailer:To provide perfect after- sales service ,our company send resident people to retailer’s country .
F.A.Q 3
1.50kgs,1.6m Long-lived hydraulic drum lifter and tilter
1.Q:Is there any discount?
A: Our factory will offer customers 3% vulnerable parts in free .
2.Q:Does your factory accept customizing?
A:Yes,pls send your reguirements to sales3(@).
3.Q: Does your factory accept Neutral Packing and Designed Brand?
A:Yes,we accept.
4:Q:Which is the nearest airport to your factory?
A:Shanghai.We can take you at the airport and provide accommodation.
