300kg Factory Price Lift Platform
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | huize | |
| Model Number | HZSJY0304-01 | Lift Mechanism | Scissor Lift | |
| Lift Drive / Actuation | Electric Motor | Rated Loading Capacity | 300kg | |
| Max. Lifting Height | 4000mm | Overall Dimensions | 1.8*1*0.9(M) | |
| Certification | CE,ISO9001,SGS,BV | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
300kg factory price lift platform
pallet truck|stacker|forklift|
1.Product drawing
|
| |
2.Main technical specifiations
1 characteristic | |||
1.1 | Name |
| Scissor Lift |
2.1 | Model |
| HZSJY0304-01 |
3.1 | Operation Type |
| Push by hand |
4.1 | Load capacity | Q(Kg) | 300 |
5.1 | Power voltage |
| 380V50HZ three phase |
6.1 | Lifting motor | KW | 1.1 |
7.1 | Scissors boom rectangular tube | mm | 100*40 |
8.1 | Scissors boom | Layer | 3 |
9.1 | Table-board |
| Diamond plate |
10.1 | Color |
| Green red blue |
11.1 | Main application |
| Indoor and outdoor decorating lamp, condole top, access road and other aloft work |
12.1 | Surface treatment |
| Paint |
2 | Hydraulic cylinder | ||
13.2 | Lifting hydraulic cylinder | mm | φ80 |
14.2 | Number of hydraulic cylinder | piece | 2 |
3 | Tire | ||
15.3 | Rechargeable tire | mm | Φ200 |
16.3 | Number of tire | piece | 4 |
4 | Size | ||
17.4 | Lifting height | hmm | 4000 |
18.4 | Operating height | hmm | 5700 |
19.4 | Guardrail height | hmm | 1000 |
20.4 | Chassis size | L*bmm | 1700 (length)*850 (width) |
21.4 | Support leg length | bmm | 500 |
22.4 | Overall length | Lmm | 1750 |
23.4 | Overall width | bmm | 970 |
24.4 | Overall height | hmm | 850 |
25.4 | Channel width | Ast(mm) | 1000 |
26.4 | Minimum channel width truck turning around | Ast(mm) | 1800 |
5 | Performance | ||
27.5 | Lifting speed (loaded/unloaded) | mm/s | 60/80 |
28.5 | Falling speed (loaded/unloaded) | mm/s | 85/81 |
6 | Weight | ||
29.6 | Gross (including packaging)/net weight | Kg | 306/300 |
7 | Production and delivery | ||
30.7 | Monthly production capacity | set | 20 |
31.7 | Delivery time for per one set | day | 7 |
8 | Packing and shipping | ||
32.8 | Packing method |
| Packaging as a whole |
33.8 | Packing |
| Angle iron + bubble wrap |
34.8 | Packing size | L/B/H(m) | 1.8*1*0.9 |
35.8 | Packing outer box of each product | piece | 1 |
36.8 | Number of 20-foot containers | set | 13 |
37.8 | Number of 40-foot containers | set | 26 |
9 | Others | ||
38.9 | Name of customs declaration |
| Hydraulic lift |
39.9 | HS code |
| 8428909090 |
40.9 | Order No |
| 17.20001 |
3.Factory profile
4.Certification:
5.FAQ
1)Q:What is the minimum order quantity?
A:Taizhou Huize Machine Co.,Ltd specialized in all kinds of pallet truck,stacker,forklift,cran,boom lift,
platform and drum truck.The minimum order is 1 pc.
2)Q:What is the production and delivery time?
A:25 days after receiving the first T/T/1*40''HQ.
3)Q:Can we use our own shipping agent ?
A:Yes,all customers can use their own shippng agent,but we advice you use our factory shipping agent.
Because we have been cooperated with the shipping company for 8 years,the cost is lower .
4) Q:Can we mix the 20ft container ?
A: Yes,you can mix it,you can mix less than 3 models in a 20FT container and 4 models in a 40FT or 40
HQ container.
5)Q:Do you have ISO system?
A:Yes, we have CE,BV,ISO9000,ISO9001 certification.
6)Q:what terms of payment you can accept?
A:We advice you choose :T/T30% deposit,or L/C at sight
7)Q:Are there any discounts for bulk orders?
A:Of course,different quantities with different prices.
8)Q: How to check quality?
A:China huize fork lift company advice all customers use your own QCS and we welcome your arrival .
Our QCS can also offer assistance and checking report if you need.
