rated weight 300kg lift height 6m scissor lift platform

FOB Price

USD $1,930 - $2,300 / Set

1 Set(Min.Order)

Product Details

Place of Origin:	Jiangsu, China	Brand Name:	HZ	Model Number:	HZSJY0306-02
Lift Mechanism:	Scissor Lift	Lift Drive / Actuation:	Electric Motor	Power:	1.5kw
Rated Loading Capacity:	300kg	Min. Lifting Height:	1150mm	Max. Lifting Height:	6m
Table Size:	1950*1000mm	Overall Dimensions:	2.051.151.24m	Weight:	666/660kg
Certification:	CE, SGS, ISO9001	Warranty:	1 year	After-sales Service Provided:	Engineers available to service machinery overseas

rated weight 300kg lift height 6m scissor lift platform

Product picture

Product description

Scissor lift platform can raise and fall in the air vertically, and is special equipment for indoor and outdoor

aerial work; Load 300kg and lift 4-14m, load 500kg and lift 4-12m, load 1000kg and lift 6-11m;380V supply

voltage three-phase electricity;Widely used for indoor and outdoor machinery installation, building

maintenance, equipment repair, station, wharf, bridge, hall, workshop.

Product parameters

1	Characteristic
1.1	Name		Scissor Lift
1.2	Operation Type		Push by hand
1.3	Power voltage		380V50HZ three phase
1.4	Scissors boom rectangular tube	mm	100*40
1.5	Scissors boom	Layer	4
1.6	Table-board		Diamond plate
1.7	Color		Green red blue
1.8	Main application		Indoor and outdoor decorating lamp, condole top, access road and other aloft work
1.9	Surface treatment		Paint
2	Hydraulic cylinder
2.1	Lifting hydraulic cylinder	mm	φ80
2.2	Number of hydraulic cylinder	piece	2
3	Tire
3.1	Rechargeable tire	mm	Φ200
3.2	Number of tire	piece	4
4	Size
4.1	Operating height	mm	7700
4.2	Guardrail height	mm	1000
4.3	Support leg length	mm	600
