300kg 11m Air Hydraulic Lifting Lift Platform

US$ 5,000 - 5,200 MOQ: 1 Set

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

Model Number:

HZSJY0311-07

Taizhou Huize Machine Limited Company

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name HZ

Model Number HZSJY0311-07

Lift Mechanism Scissor Lift

Lift Drive / Actuation Electric Motor

Power 2.2kw

Rated Loading Capacity 300kg

Min. Lifting Height 1550m

Max. Lifting Height 11m

Table Size 2350*1320mm

Overall Dimensions 2.4*1.35*1.6m

Weight 1556/1550kg

Certification CE, SGS, ISO9001

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

300kg 11m air hydraulic lifting lift platform

Product picture

Product description

1.Load 300kg and lift 4-14m, load 500kg and lift 4-12m, load 1000kg and lift 6-11m;

2.380V supply voltage hree-phase electricity;

3.Widely used for indoor and outdoor machinery installation, building maintenance,

equipment repair, station, wharf, bridge, hall, workshop.

Product parameters

1	Characteristic
1.1	Name		Scissor Lift
1.2	Operation Type		Push by hand
1.3	Power voltage		380V50HZ three phase
1.4	Scissors boom rectangular tube	mm	120*40
1.5	Scissors boom	Layer	6
1.6	Table-board		Diamond plate
1.7	Color		Green red blue
1.8	Main application		Indoor and outdoor decorating lamp, condole top, access road and other aloft work
1.9	Surface treatment		Paint
2	Hydraulic cylinder
2.1	Lifting hydraulic cylinder	mm	φ80
2.2	Number of hydraulic cylinder	piece	3
3	Tire
3.1	Rechargeable tire	mm	Φ400-80
3.2	Number of tire	piece	4
4	Size
4.1	Operating height	mm	12700
4.2	Guardrail height	mm	1000
4.3	Support leg length	mm	600
