MLK25CA soft icecream machine description
Model No.:MLK25CA
Production :25L/H
Compressor: Panasonic
Voltage:220v/50hz/60hz
Power: 1850w
Gas: R22/R404a
Size: 715*560*1380mm
Noise: 36db
Powerful Technology and Spare Parts Used on MLK25CA soft icecream machine
1. Compressor:panasonic
2. Condensor:full copper condenser with two inlet connector for anti-shake
3. Motor: famous motor applied by most factories in china
4. gear box :strong cast iron gear box wih metal gears (most chinese factories use plastic gears )
5. capillary:full copper capillary
6: hopper:#304 stainless steel hopper without welding (some factories use plastic hopper and do welding on hopper )
7. Outside design: painted in one color or full stainless steel
8: inner side: painted with black color (some factories not painted inside with only raw material)
9: handle: with rubber inside holes for noise cutting
10: discharger block: with a slide angle for strengthening and crack protection
11.mother board and displayer: mother board is a matured chips design which used for more than 10 years ,all information can be displayed on like cones ,temp,shift ,trouble-shooting etc
12.anti-break copper design inside
Package and Shipping For MLK25CA soft icecream machine
1. Wooden base plus carton box
2. Wooden crate (with extra packing charge)
3. sea shipment or air cargo
FCL: full container load recommended for transportation
LCL: less than container load ,must take care and with shipping mark
After Sales Service For MLK25CA soft icecream machine
1. with 1% total container value spare parts sent together with shipmen
2. additional spare parts charged with factory cost
3. all cooperation based on long time contract
Features About Miken Ice Cream Machine
Before you choose an ice cream machine type , you must select well and carefully that the machine is with Ampere Control System or Speed Control System. If it is Ampere Control System, you must be mind of the unstable voltage ,this will cause serious problems for ice cream machine in unstable voltage area. If it is Speed Control System, this one is ok for all areas. But the precision of viscosity for ice cream not exactly 100% display like Ampere. But this system is popular all worldwide.
Below are several points for Miken Ice Cream Machines
1>Size Bigger
Table top model with size 560*715*780mm
Floor standing model with size 560*715*1380mm
Q:Why choose bigger size ?
A:bigger size means with more space inside machine which is better for air circulation and copper winding. Like the famous brand TALOR ice cream machine ,all are with bigger base.
2>Compressor
Our first choice is Panasonic which we have used a lot on our ice cream machine for domestic market and oversea market like Indonesia ,South Africa ,Chile , Philippine, Vietnam, USA, Canada, England, Iraq etc with sub tropical area to tropical area. Panasonic in those countries all perform well.
Our second choice is Embraco Aspera, this brand we use under requirement but we do not recommend duo to its high cost and no warranty in market. The cost is more than budget. And in fiddy’s last 10 years experience , many friends still get problems with this brand compressor and still cannot analysis what cause the problems without embrace aspera company support.
3>Condenser
We use full copper condenser while many other ice cream machine factories start to use aluminum pipe as heat exchanger conductor. Two copper pipe inlets and single copper pipe outlets for copper anti-shake design.
4> Gear box
Metal gears used on my ice cream machines while many other factories use plastic gear for cost consideration. Metal gears are about triple times cost higher than plastic. Metal gears cause less noise and stable performance on speed control than plastic.
Casting mould are for leakage protection on gear box, all our gear box body part never get leaked.
5> PCB board and Indicator
Miken ice cream machine PCB board get a function to automatically recognize the rotate speed on wheels. This function makes speed control system more functionalize in different area and situation.
Many functions like below you can read by indicator :1.low voltage protection 2.speed verification adjust nes record 4.standby time set 5.speed recognition 6.operation mode with pre-cooling or without pre-cooling system.7.temperature 8.trouble shot 9.shift for hardness and softness
All these functions are well implemented in the PCB board and Indicator
6>Air pump
Miken ice cream machine if installed with air pump can work more efficiently on more overrun of ice cream. There is a test about the overrun about 20 to 30% higher.
Our air pump works only when press “freeze” button. It works 8 seconds and stop 8 seconds for a better life span of this system . other factories install air pump and never stop once switch on machines .
7>Motor position can be adjust to make a proper tight belt
You can screw up or down to re-fix motor position to adjust a proper tight belt. Motor another side mounted with rubber fixer for noise cut
8>Imported material on O ring for a smooth friction and easy press down handle
9>Anti-crack discharger design and all new imported ABS used on discharger
10>Less gap between beater and internal of cylinder for a better taste
11>Anti-shake copper design for life time copper break
12>removable leakage holder
13>brand single pass away valve
14>famous solenoid valve
15>high quality filter
16>big horse eye design panel
17>hopper and top cover connection without welding
18>3cm top cover edge design
19>high efficiency evaporator design
20>all machines with high temp test (35 celse degree to42 celse degree)
21>top micro-switch
