Help CenterDisposable Cup Making Machine
Related Products
Specifications
TF-660 disposable cup making machine is suitable for forming different cup and bowl.TF-660 disposable cup making machine is a combination of mechanical, electrical and pneumatic components, and the whole system was controlled by micro PLC. It is operated with man-interface, fed the sheet by chain and formed by cam system, It combines the material feeding, heating, drawing, forming, cutting and transporting into one process.
Application Area:
It is suitable for forming PP,HIPS,PET,PVC,PE plastic sheets, which can be widely used to produce all kinds of plastic boxes, containers and other plastic wares, such as ice-cream cups, milk cups, chocolate package boxes, candy boxes, candy boxes and fast-food boxes etc.
Main Technical Parameter:
Max. Forming Area: 620*250mm
Max. Forming Depth: 125mm
Production Speed: 10-35 Cycles/min
Power: 3×380V+NP+PE.50HZ
Sheet width: 400-630mm
Heating power: 70kw
Sheet thickness: 0.25-2.5mm
Main motor power: 11kw
Max. Rolling diameter: Φ800mm
Feeding motor power: 2.2kw
Air pressure: 0.7mpa
Scrap rewinding motor power: 0.37kw
Water consumption: 50L/min (15-20 degrees)
Air consumption: 2000L/min
Overall Dimension: 3300×1650×2250mm
Weight: 5000kg
Send Inquiry to This Supplier
