Disposable Food Container Forming Machine

Specifications

Disposable Food Container Forming Machine is forming different disposable food container and fast food box.

Disposable Food Container Forming Machine adopts the most advanced plastic thermoforming technology and was developed to be a forming machine of high production efficiency. It is a combination of mechanical, electrical and pneumatic components and the whole was controlled by micro PLC. The machine has man-interface operation. Combines heating, forming,cutting  into one process.

Application Area:
It is suitable for forming HIPS, PS, PVC, PET, PP sheet that can produce disposable food container,fast food boxes,boxes, trays, dishes, lids, cookies tray, mobile phone tray & other blister tray.

Main Technical Parameters:

Mode:RHC-600/500
Max. Forming Area: 600*500mm
Max. Forming Depth:100mm
Sheet Thickness Range: 0.15-1.5mm
Max. Sheet Width: 640mm
Air Pressure: 0.8Mpa
Speed: 360-1200 cycles/h
Heater Power: 32kw (Upper Heater)   24kw (Lower Heater)
Punch Pressure: 20tons
Upper Mold Table Stroke: 120mm
Lower Mold Table Stroke: 120mm
Max. Mold Depth: 120mm
Power: 3 Phases 1 Phase 380V/220V
Max. Hydraulic Pump Pressure: 21Mpa
Max. Cutting Length: 8650mm
Machine Total Power: 72kw
Overall Dimensions: 8500*1400*2100mm
Weight: 5000kg
