Second hand Rubber Dispersion Kneader on sale.
Used Rubber Dispersion Kneader on sale.
Old Rubber Dispersion Kneader on sale.
Brand: KNEADER (Taiwan)
Age:4 years
Condition: Normal operation.
Technical Parameters: |
|
- Model |
X(S)N-75L |
- Total Chamber volume |
180L |
- Working chamber capacity |
75L |
- Rotor |
2 Wing Type |
- Rotor speed |
32 : 25 RPM |
- Friction Ratio |
1.28 : 1 |
- Input Motor |
110 KW |
- Main Motor voltage |
380V |
- Batch weight |
Approx. 75-120 kg |
- Mixing Cycle Time |
Approx.8- 12 mins. |
- Discharge Door |
Front opening type |
- Charging Door |
Back door feed |
- Working Air pressure of Ram |
0.6-0.8 MPa |
- Ram pressure on compound |
0.38 – 0.51 MPa |
- Cooling arrangement |
Required for Rotors /Chamber/Ram |
- Tilting Motor |
4 KW geared brake motor with planetary gearing |
- Tilting angle |
140 degree |
- Rotor |
Steel cast machined and hard chrome plated |
- Side Board |
Steel cast machined and hard chrome plated |
- Main chamber |
Steel cast finish machined with Thermocouple &Sensor |
- Top lid/Pressure lid |
Steel cast duly finish machined |
- Pneumatics |
Suitable for 6 to 9 Kg/cm2 air pressure control /interlock |
- Rotor Seals |
By-Mechanical Seals with double combination sealing |
- Reduction Gear |
Multistage, Hardden Gear Reduction Gearbox |
- Dimension (mm) |
L3800xW2140xH3180 |
- Weight (Kg) |
5000 |
Accessories |
|
a) Rotor seals: 2 sets |
|
b) Pneumatic cylinder: 2 sets |
|
c) Lubrication gun: 1 set |
|
d) Solenoid valve and pressure gauge: 1 set |
|
e) Travel switch: 1 PCS |
|
f) Tools set: 1 set |
