LED MR11Sport Lighting Led MR11 2W 12V Lamps
Features:
- 1pcs High Power 1-3W LED as lighting source.
- No glare, no noise.
- Aluminium material housing with excellent heat conduction.
- Life span up to 25,000hours, the LED efficiently protected by constant current power.
- As a replacement of traditional led spotlight.
- Environmental protection, no mercury and hazardous substances.
- Widely used for indoor lighting, such as hotel, restaurant farm and home lighting, etc
| Specification | ||||
| Electric Parameter | ||||
| 1 | Item Number | MR11B-1*1W-W | MR11B-1*1W-WW | |
| 2 | Power Consumption/W | 1W±10% | ||
| 3 | Input Voltage/V | AC/DC12V;AC100-240V | ||
| 4 | Input AC Current/A | 0.208A @ AC/DC12V | ||
| 7 | Drive Mode | Constant current driver | ||
| 5 | Energy efficiency index | ≥0.6 | ||
| 6 | Energy efficiency level | A | ||
| 8 | Start Time | ≤360ms | ||
| 9 | Maximum duty cycle | ≤0.45 | ||
| 10 | Short Circuit Protection | Yes | ||
| 11 | Open Circuit Protection | Yes | ||
| 12 | Reverse Polarity Protection (RPP) | Yes | ||
| 13 | Temperature Protection | Yes | ||
| 14 | Safety Grade | Class Ⅲ | ||
| Optics Parameter | ||||
| 1 | LED | Origin | Epistar | |
| LED Bright | 80-95LM/led for White @ 700mA | 80-95LM /led for Warm White @ 700mA | ||
| LED Color Temperature | 6000-6500K | 2700-3200K | ||
| CRI | ≥70% | ≥70% | ||
| 2 | Lamp | LED Packing type | High Power 1-3W LED / 1PCS | |
| 3 | Current / Whole lamp / mA | 400±20mA | ||
| 4 | Initial brightness/LM | 160LM±10% | 145LM±10% | |
| 5 | Initial Light Efficiency/LM/W | 80LMW±10% | 72.5LMW±10% | |
| 6 | Beam Angle | 25° | ||
| 7 | Luminosity Under 0.75m Distance | 1600lux±10% | 1400lux±10% | |
| 8 | Luminosity Under 1.50m Distance | 160lux±10% | 135lux±10% | |
| 9 | 1000 hours Light failure rate | < 5% @ 25°C | ||
| Structure parameters | ||||
| 1 | Lamp base | MR11 | ||
| 2 | Lamp body type | led Spotlight | ||
| 3 | Sheel Structure material | Aluminium lamp body | ||
| 4 | Net Weight/Lamp | 22±5g | ||
| 5 | Packaging Information | 1pc/gift box 75pcs/carton NW: 2.5kgs/ctn GW: 3.5kgs Carton Size:26.5*21.5*20CM | ||
| Reliability | ||||
| 1 | Bump test | OK | ||
| 2 | oscillate test | OK | ||
| Environment parameters | ||||
| 1 | Working Temperature | -20°C - 40°C | ||
| 2 | Storage Temperature | -20°C - 60°C | ||
| 3 | Theoretical Lifespan at 25°C / Hr | 25000H=25years(≈2.7H/day) | ||
Details of MR11 LED Spot Light:
Recently Attended Trade fairs:
a).Guangzhou Fair , 15-19 October 2012 Booth :13.2 C02-03
b).HK International Lighting Fair, 27-30 October 2012 Booth :5E-D34
c).Lighting Japan, 16-18 January 2013 Booth :W9-58
d).Guangzhou International LED Fair, 1-4 March 2013 Booth :11.3-E11
e).HK International Lighting Fair(Spring Edition), 6-9 April 2013 Booth: 1D-E07,E09
f).Guangzhou International Lighting Exhibition, 9-12 June 2013 Booth: 11.3 A09
g).HK International Lighting Fair(Spring Edition), 6-9 April 2013 Booth: 1D-E07,E09
h).HK International Lighting Fair(Autumn Edition), 27-30 October 2013 Booth: 5E-G02
