Nanjing Mixer Xk-450 Two Roll Rubber Mill/rubber Mixing Mill Price
US$ 1 - 99,999
/ Set
1 Set(Min. Order)
- Shanghai Ninbo
- T/T Credit Card
You May Like
-
Xk-450 Open Rubber Two Roll Mill/open Mill Rubber Mixing Machine
-
400 Open Two Roll Rubber Mixing Mill/compound Rubber Product Line/twin Roll Plasticizing
-
Two Roller Open Rubber Resin Mixer Machinery
-
Roller Mixer/compounds Rubber Mixing Machine
-
Double Shaft Paddle Mixer Laboratory/rubber Rolling Mill
-
Nanjing Mixer Rubber Two Roller Open Mixing Mill Machine
Product Details
| Condition | New | Type | Open Mixing Mill | |
| Place of Origin | Jiangsu, China | Brand Name | Mixer | |
| Model Number | X(S)K -450 | Voltage | as customer's requirement | |
| Power(W) | 90/110kw | Dimension(L*W*H) | 6290x2330x1780mm | |
| Weight | 20000kg | Certification | CE | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
xk-450 two roll rubber mill/rubber mixing mill price
Product Description
Used for rubber&plastic mixing,sheeting.
Features:
· Tailored structure,stable performance, easy to operate.
· There are varied speeds and fraction ratios available, which can satisfy most customers’ formula and processing requirements.
· Frame, frame cap and base, looking very nice, are welded and treated by annealing for stress relieving.
· Chilled alloy cast iron roll is abrasion resistant with long service life.
· The speed reducer is the hard-tooth surface gear reducer of Class 6 precision, which has long service life and low noise.
· Perfect emergency stop device can ensure the safety of personnel and equipment.
· The seal structure with special design can eliminate the leaking phenomenon of lubricating oil.
· Stock pan is easy to clean up with dislodging device.
· Human nature designed operating system reduces labor intensity.
· Modular structure offers various structures for customers’ option.
· The flexible design system can satisfy customers’ special design requirements within the shortest time.
· A load test running will be made to the assembled equipment in our company to save debugging time for customers.
Specification
Model | X(S)K-160 | X(S)K -250 | X(S)K -360 | X(S)K -400 | X(S)K -450 | X(S)K -550 | X(S)K-660 | |
Diameter of rolls | 160 | 250 | 360 | 400 | 450 | 550 | 660 | |
Working length of roll | 320 | 620 | 900 | 1000 | 1200 | 1500 | 2130 | |
Working speed of front roll | 8.95 | 14.9 | 17.4 | 19.3 | 23.1 | 28.6 | 30 | |
Fraction ratio of rolls | 1:1.35 | 1:1.1 | 1:1.27 | 1:1.27 | 1:1.27 | 1:1.29 | 1:1.05 | |
Max.gap(mm) | 5 | 8 | 10 | 10 | 10 | 15 | 15 | |
Nip regulating mode | Manual | Manual | Manual | Manual or Electric | Manual or Electric | Manual or Electric | Electric | |
Batch capacity(Kg) | 1-2 | 10-15 | 20-15 | 25-35 | 30-50 | 50-60 | 120-140 | |
Motor | Power | 5.5 | 15 | 30 | 45 | 55 | 90/110 | 180 |
Motor speed(r/m) | 1440 | 730 | 980 | 740 | 980 | 740 | 740 | |
Reducer | Full closed type hardened gear speed reducer | |||||||
Reduction ratio | 43 | 35 | 49.7 | 38 | 47.2 | 35.6 | 126.2 | |
Overall dimension (mm) | 1120x920 X1295 | 3400x1270 X1620 | 4140x1770 X1700 | 4490x1700 X1750 | 5570x1900 X1750 | 6290x2330 X1780 | 7500x 2630x2060 | |
Weight (kg) | 1100 | 4200 | 7600 | 9000 | 11500 | 20000 | 26500 | |
