Application
Product Features
Rating Current:80A -320A
Rating Voltage:150v
Specification:
1.Silver-plated contact
2.Different contact barrel size for choice(4AWG-3/0AWG e.g.)
3. design to reduce the stocking
4.Difference color recommended different voltage code
5.Quick connect/disconnect
6.Operating temperature: -25°C ~ +105°C
7.Withstand voltage:2200V
8.Mechanical life: 10000 times
Our Advantage:
1.The products series completely,from multi pole to single pole,from low amps to high amps
2.Different color housing is available
3.Different contact barrel size for choice
4.International approvals(UL,CE,ROHS)
5.Competitive price
6.Prompt Delivery time(7-10 days)
7.Guaranteed quality
8.OEM order is acceptable
UL,ROHS,CE approvals
Adapt socket type : EC80/EC160/EC320
|
EC80 |
EC160 |
EC320 |
UL Rating Voltage |
80amps/150vdc |
160amps/150vdc |
320amps/150vdc |
Diameter range |
Main terminals #8-#2(10/35)Auxiliary terminal #18-#14(1.5/2.5) |
Main terminals #6-#1/0(16/50)Auxiliary terminal #12-#10(4/6) |
Main terminals #1/0-#4/0(50/95)Auxiliary terminal #18-#10(1.5/6) |
average terminal holding force |
About 100lbs |
About 100lbs |
About 100lbs |
average contact resistance |
2awg (35mm2)wire 65 micro-ohms |
1/0awg (50mm2)wire 55 micro-ohms |
4/0awg (95mm2)wire 30 micro-ohms |
average insertion force |
12lbs (53N) |
12lbs (53N) |
12lbs (53N) |
Anti-acid |
1.38g/cm2 |
1.38g/cm2 |
1.38g/cm2 |
Waterproof rating |
IP23 |
IP23 |
IP23 |
Shipment:FOB shanghai,by sea,by air.Fedex,TNT,DHL,UPS
Packaging Details: bubbles wrap over products.strong heavy carboard carton
