Vacuum Rubber Washer Cutting Machine/Automatic Rubber Tube Cutting Machine

Vacuum Rubber Washer Cutting Machine/Automatic Rubber Tube Cutting Machine photo-1
Vacuum Rubber Washer Cutting Machine/Automatic Rubber Tube Cutting Machine photo-2
Vacuum Rubber Washer Cutting Machine/Automatic Rubber Tube Cutting Machine photo-3
Vacuum Rubber Washer Cutting Machine/Automatic Rubber Tube Cutting Machine photo-4
US$ 1 - 99,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
MIXER
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Jiangsu, China
Brand Name MIXER
Model Number YMQ-200M
Voltage 380V
Power(W) 1.2 KW
Dimension(L*W*H) 130x90x150cm
Weight 300 KG
Certification ISO
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas



Product Description

  Vacuum Automatic Rubber Washer Cutting Machine/Automatic Rubber Tube Cutting Machine :

Application:
Fast cut of all kinds of rubber, silicone gaskets/ washer, ring-shaped tubular products.
Features:
1. When the cut is finished, materials take off automatically, and through the collection boxes to gather the cut products.
2. Vacuum adsorption of the cut product, so ensuring the finished product more precise.
3. Automatic air blowing function makes loading and unloading more convenient , greatly improve the product cutting efficiency;
4. Using color LCD touch screen control, operation is extremely simple.
5. All electrical components, pneumatic components are imported from abroad or domestic famous brand products, to ensure long-term use, reliability and stability of the new machine.
6.  According to customer requirements, choose to install a round knife or column knife, ensuring cost saving on the cutter.




Specification



Cutting efficiency
>60 times/minute
Working rotating speed
0~2000r/min
Cutting precision
≤±0.05mm
Cutting diameter
Φ10mm~Φ230mm
Cutting length
Standard type≤100mm or lengthen type≤350mm
Wall thickness of the rubber tube
≤12mm
Finished product thickness
≥0.02mm
Cutter specification
(1)round cutter:Φ76×Φ25.4×Φ0.3mm (2)column cutter:70×8×0.3mm
Compressed air consunption
20L/min
Air pressure
0.5MPa~0.8MPa
Working vacuum degree
≤-0.035MPa
Electric power
AC220V±5%
Total power
1KW
Weight
≈260Kg
Dimension of the machine(L×W×H)
130cm×90cm×150cm
