AZO zinc and aluminum oxide solution manufacturer

zinc and aluminum oxide solution is high temperature resistance and stability, good electrical conductivity.

Metal oxide which doped aluminum to ZnO is know as AZO, the product is a relatively cheap, and cost-effective, environmentally sound transparent conductive material.

Maximum tolerable temperature can reach 1975 °C, conductivity deposition by evaporation could reach the limit 6 × 10⁴Ω.cm, and high temperature stability is also very strong. It is considered as the most potential nano-materials for 21^st century, can be widely used in transparent insulating film, transparent conductive film and IT industries on a variety of transparent electrodes.

1 AZO powder,model code:AZO-P100

2 AZO water-based solutions,

two sections according to different concentration

AZO-WP010

AZO-WP020

3 AZO oil-based solutions,

two sections according to different concentration

AZO-MP010

AZO-MP020

Model code	AZO-P100	AZO-WP010	AZO-WP020		AZO-MP010	AZO-MP020
Concentration	99.99%	10%	10%		10%	20%
Product name	AZO powder	AZO water-based solution			AZO oil-based solution
Appearance	White powder	Milky white translucent liquid			Milky white translucent liquid
Proportion	ZnO :AL2O3 =99%:1%	ZnO :AL2O3 =99%:1%			ZnO :AL2O3 =99%:1%
Specific surface area	30-50 square meter/g	30-50square meter/g			30-50square meter/g
Primary particle diameter	20-40nm	20-40nm			20-40nm
Secondary particle diameter	3-5um	80-100nm			80-100nm
Purity	≥99.9%	≥99.9%			≥99.9%
Resistance	1.2×101Ω.cm	1.2×101Ω.cm			1.2×101Ω.cm
PH value	5-9	(7-9)±0.5			(7-9)±0.5
Solvent	/	Water			Isopropyl alcohol, ethanol, ethyl acetate, acetone, butanone, toluene, xylene and butyl acetate
Main applications	Being widely used in the production of transparent conductive anti-static coating: As a conductive film liquid on crystal display (LCD). Being applied to touch-type display. CRT anti-radiation (EMI, RMI) protection of high-transmittance microscope. Energy conservation and the protection of privacy with the switch-mode transmittance glass (Switch Glazing), also used in the buildings & automotive windows. Applied to the surface of the sensor. Applied to anti-reflective film. As antifogging and heating panels in boreal regions As conductive film for optoelectronic components, such as solar cells, light-emitting diodes, photovoltaic crystals. As electrode for organic light-emitting diodes.
Packaging specifications	1/2/20KG			1/2/20L
