AGM SLA Storage Battery Manufacturer 12v4ah Korea

Name: AGM SLA Storage Battery Manufacturer 12v4ah Korea
Brand: kang li da
SKU: 129274875
Availability: InStock

US$ 5.5 - 9.55 MOQ: 500 Pieces

Key Specifications

Place of Origin:

Henan, China

Brand Name:

kang li da

Model Number:

CA1240

Zhengzhou Kanglida Electronic Power Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name kang li da

Model Number CA1240

Usage Other, Building interphone

Voltage Other, 12v

Sealed Type Sealed

Maintenance Type Free

Size 90*70*101mm

Weight 1.25kg

Nominal Capacity 4ah

Specifications

AGM SLA storage battery manufacturer 12v4ah Korea is
1.Size:90*70*101mm
2.Weight:1.25kg
3.CE certification

Advantage

1.The battery is full of power when it’s out of factory, no need to use liquid charge;

2.no memory, no need to discharge battery use, suitable for circuit design;

3.by high partition, adsorption and strong;

4.there is no flowing liquid (poor liquid), does not leak acid and free Upside down,

ply with environmental requirements, ease of use,

6.the use of lead-calcium alloys, battery self-discharge is very low,

7.easy storage, less maintenance;

8.using ABS plastic shell and valve technology for safe use.

Application

AGM SLA storage battery manufacturer 12v4ah Korea can be used in building interphone, fire alarm system and so on.

battery characteristic
Nominal voltage				12V
Nominal capacity(20h rate)				4Ah
Size		Total height		101mm
		length		90mm
		width		70mm
		height		101mm
Weight				1.25kg
Rated capacity 25°C(77°F)	20 hour rate(0.20A)			4.0Ah
	10 hour rate(0.4A)			3.2Ah
	5 hour rate(0.70A)			3.0Ah
	1 hour rate(2.5A)			2.7Ah
Internal resistance	in full charge status 25°C(77°F)			35mΩ
Capacity at different temperature(10h)	40°C(104°F)			102%
	25°C(77°F)			100%
	0°C(32°F)			85%
	-15°C(5°F)			65%
Self discharge 25°C(77°F)	capacity after 3 months			91%
	capacity after 6 months			82%
	capacity after 12 months			64%
Mode of charge (constant voltage) 25°C(77°F)	cycle-use		initial charging current less than1.80A , voltage14.10-14.40V
	float-use		Initial charging current less than 0.68A voltage13.5-13.80V

Notice

Don’t near the hot source and don’t under the sunshine.
Don’t charge in the sealed container.
No short circuit. It should be addition charge if you don’t use, and single charge per three months, to avoid irreversible sulfating. The battery should be changed when the battery jar broken or the electrolyte omitted, to avoid acid corrosion.
Don’t store in the space of acid gas.
You should be careful and regular check when use the battery. To avoid the battery don’t work. You should change the battery if the capacity is not full or has been damage, especially after one year using.
Don’t put the battery in the fire, or it will explode.
Please use cotton cloth to clean, if the battery is broken down and leak electrolyte. Please wash your skin when touch the electrolyte.
Don’t clean the battery by using the organic solution. (e.g. petrol)
