Newest Type and Easy install JS 500 concrete mixer for small construction machine HZS25 concrete batching plant
Model: JS500
Mixing equipment: Streamline for the axial and radial of the mixing arm, not only for the axial cutting of the
materiel, but also can for more efficiency of radial pushing function, dramatic stir for the materiel,so it can
reach the homogeneous state of the concrete. Due to the special design of the stirring device, improving the
utilization of the cement.
Transmission: Adopts two planet gear speed reducer for transmission, which are of compact structure,
stable transmission, and long service time.
Full automatic oil lubrication system: All the lubricating points are lubricated by electric grease pump through
progressive distributor, High oil pressure, large viscosity and small electricity consumption, has reduced the
concrete pollution made by oil.
JS500 concrete batching plant technical parameters
Type |
JS500 |
JS750 |
JS1000 |
JS1500 |
JS2000 |
JS3000 |
Charging Capacity |
500L |
750L |
1000L |
1500L |
2000L |
3000L |
Discharging Capacity |
800L |
1200L |
1600L |
2400L |
3200L |
4800 |
productivity(m³/h) |
20-25 |
30-45 |
50-60 |
≤90 |
120 |
180 |
Power of mixing motor(kw) |
18.5 |
30 |
37 |
2*30 |
2*37 |
2*55 |
aggregate size(mm)Gravel/pebble |
60/80 |
60/80 |
60/80 |
60/80 |
60/80 |
60/80 |
Mixing motor speed |
35r/min |
35r/min |
25r/min |
21r/min |
|
|
Lifting Motor Power(kw) |
5.5 |
7.5 |
18.5 |
22 |
|
|
Lifting Motor Speed(m/min) |
18 |
18 |
18 |
18 |
|
|
Packaging 1, Waterproofing packing;
2, Corrosion resistant packing ;
Shipping 15 working days after payment
We are here to serve you
1, We provide lifelong maintenance after sale service and parts supply for the products.
2, We will help you install the quipment.
3, Be free to call us whenever there is something wrong with your concrete plants.
About us
Hebei Double Star Machinery Manufacturing Co., Ltd was established in Xingtai Hebei, covering ove r 99960 square meters area. We have more than 300 staff members, which more than 40 are engineers a nd technicians. We are the professional producer of concrete machinery equipment which incorporate scientific research, produce, before-sale service and after-sale service as a whole.
Our leading products are mainly divided into three kinds. First JS series concrete batching machine,
and second, different types of concrete batching machine, such as HZS25,HZS35,HZS50,HZS 60,HZS75,HZS90,HZS120,HZS180,HZS240 and so on. Third one, WCZ stabilized soil mixing station equip ment.
Our slogan: Built our brand by higher quality,attract our customers by feature service.
