400kw Volvo Generator

Name: 400kw Volvo Generator
Brand: Volvo
SKU: 129249759
Availability: InStock

US$ 30,000 - 350,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

Volvo

Model Number:

SMV, Saint Meilan

Fujian Saint Meilan Motor Wiring Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Fuzhou Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name Volvo

Model Number SMV, Saint Meilan

Output Type AC Three Phase

Speed 1500RPM/1800RPM

Frequency 50/60Hz

Rated Power 10kva--1250kva

Rated Voltage 110V/240V, 220V/380V, 230V/400V, 240V/415V

Rated Current 5-2000A

Specifications

400kw Volvo Generator
1 stamford,leory somer
2 Noise 70 db
3.CE&ISO,SONCAP,COI,SGS
4.Industry

400kw Volvo Generator

Generating Set Data
Generating Set Model	SMLV-260
Generating Set Power	Prime power(50Hz)	Standby power(50Hz)
	260KW/325KVA	286KW/358KVA
Rated Voltage / Frequency	400/230V, 50Hz, 3-phase, 1500rpm
Dimension (mm)	315011001600
Engine Data
Engine Model	VOLVO TAD941GE
Air Intake System	Turbo Air to air intercooler
Fuel System	Directly Injection Fuel System, Bosch Pump
Cylinder Arrangement	6 in line
Max. Standby Power at Rated RPM	308KW/419HP (with fan)
Bore×Stroke	120*138(mm)
Displacement	9.36L
Compression Ratio	17.4
Rated Speed	1500r/min
Governor	EMS2
Exhaust Gas Flow	52.2m3/min
Exhaust Temperature	519°C
Max Back Pressure	10kPa
Alternator Data
Alternator manufacturer	Stamford
Connecting Type	3 Phase and 4 Wires, “Y” type connecting
Voltage Regulation, Steady State	≤±1%
Alternator Capacity	350KVA
Alternator Efficiencies	93.5%
Air Cooling Flow	0.8m³/s
Generating Set Data
Voltage Regulation	≥±5%
Voltage Regulation, Stead State	≤±1%
Sudden Voltage Warp (100% Sudden Reduce)	≤+20%
Sudden Voltage Warp (Sudden Increase)	≤-15%
Voltage Stable Time (100% Sudden Reduce)	≤4S
Voltage Stable Time (Sudden Increase)	≤4S
Noise Level	114dB
