UK Fg wilson engine company is the world-famous engine corporation. It has the glorious engine production sale history. Founded in 1932 by British entrepreneur Frank·fg wilson in Britain.

FG WISLON- Rolls-Royce engine, application of the latest electronic fuel injection control system.

It has small volume,light weight, reliable performance,low consumption. The exhaust emission

achieve German TALUFT standard, American EPA Tier 3 standard, EU-3 standard

SAINT-fg wilson generator set, selects original fg wilson engine from fg wilson engine (UK) company. It also include alternator, base frame, connecting flange, fuel tank, and control system,etc..

Alternator

Engine can be coupled with WT series A.C.synchronous brushless alternator( new-style designed by ourselves,with update international technology). It can also be matched with STAMFORD,LEORY SOMER, MARATHON alternator according to customers’ demand.

Gensets can be open type or soundproof (silent) type.

Gensets’ electric performance

Gensets compliance with all main standards,such as :GB/T2820,ISO8528,IEC34,VDE0875-N

Prime output power: 1700kw

FG Wilson engine model: 4016-61TRG3

Rated voltage:400/230v, 440/254v, 220/127v, etc.

Phase/connecting method: 3 phase 4wire/Y type connection

Rated frequency: 50/60hz

Rated speed: 1500/1800rpm

Excited type: Brushless, self excited or PMG

Insulation: Class H

Protection: IP21~IP23

Voltage regulation: AVR automatic control

Altitude above sea level: ≤1000 meters

Ambient air temperature: ≤40 centigrade

Relative air humidity: ≤ 90%

Controller system

1.Standard control panel, including voltmeter, fequency meter, ampere meter,water temperature gauge, oil temperature gauge, oil pressure gauge, AMF control module,oil level indicator, emergency button,preheating button, battery voltage gauge, hours running counter for protection and tranfering.

2.It can be with ATS electric control cabinet, including circuit breaker,  LCD or LED auto controller, indicating lamp, transfer switch,etc.. Automatic transfer switch (ATS) uses update technology, which can be automatic control for on-off electricity, remote monitoring, automatic parallel operation,etc…
