Home > Electrical & Electronics > Electric Motor > AC Motor > Three Phase MS Series Induction Motor

Three Phase MS Series Induction Motor

Name: Three Phase MS Series Induction Motor
Brand: Electic Motor
SKU: 129246047
Availability: InStock

Three Phase MS Series Induction Motor thumbnail-1

Three Phase MS Series Induction Motor photo-1

US$ 30 - 120 MOQ: 1 Set

Key Specifications

Get Latest Price

Brand Name:

Electic Motor

Model Number:

MS8022

Type:

Induction Motor

Contact Supplier Request Quote Chat Now

Fujian Saint Meilan Motor Wiring Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in china

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name Electic Motor

Model Number MS8022

Type Induction Motor

Frequency 50 /60 HZ

Output Power 1/6HP- 500HP

Protect Feature Explosion-proof

Phase Three-phase

Certification CCC, CE, ROHS, Other, CCC, CE, ROHS, ISO9001,SONCAP

AC Voltage 208-230 / 240 V

Place of Origin Fujian, China

Efficiency IE 2

Specifications

Induction Motor
Single/Three-phase Motor,IP54 Insulation
Class B,F Insulation
Aluminium Frame
Cast Iron Frame

Three phase MS series Induction Motor

MS Aluminium housing three phase electric motor

MS Aluminium housing three phase electric motor are acknowledged that having a good fame for quality and reliability, they are suitable for driving machines which do not have special requirement, such as machine tools, pumps, blowers, etc.
- Superior finish - Externally Ventilated - Light weight construction
- Top mounted terminal box - IP55 Protection
- Interchangeable foot mounting and flange mounting - Motor frame Size form 56-160 - 2,4 and 6 pole

Operating Condiyions:
Ambient temperature: -15°C≤θ≤40°C
Above sea level: not exceed 1000m
Rated voltage: ±5%

Use:

MS Series motors are widely applicable to food machine, blower and other machinery and equipment.

MS Series Three-Phase Asynchronous Motor Technical Data:

MS Series Three-Phase Asynchronous Motor With Aluminum Housing
Type	Output		Current	Power Factor	Eff	Speed	Tstart/Tn	Ist/In	Tmax/Tn
Type	HP	KW	(A)	(cosφ)	(%)	(r/min)	Tstart/Tn	Ist/In	Tmax/Tn
MS5612	1/6	0.09	0.32	0.68	62.0	2758	2.3	6	2.4
MS5622	1/6	0.12	0.38	0.71	67.0	2780	2.3	6	2.4
MS5632	1/4	0.18	0.53	0.75	69.0	2780	2.3	6	2.4
MS6312	1/4	0.18	0.53	0.75	69.0	2715	2.2	6	2.4
MS6322	1/3	0.25	0.69	0.81	68.0	2715	2.2	6	2.4
MS6332	1/2	0.37	0.99	0.81	70.0	2715	2.5	6	2.7
MS7112	1/2	0.37	0.99	0.81	70.0	2690	2.2	6	2.4
MS7122	3/4	0.55	1.40	0.82	73.0	2715	2.2	6	2.4
MS7132	1	0.75	1.83	0.83	75.0	2700	2.6	6	2.9
MS8012	1	0.75	1.83	0.83	75.0	2730	2.2	6	2.4
MS8022	1/5	1.10	2.58	0.84	77.0	2746	2.2	6	2.4
MS8032	2.0	1.50	3.43	0.84	79.0	2770	2.8	6	3.1
