Specifications
1 CE2 Warranty
Good Quality AC Automatic voltage regulator MX341 Free Shipping
The avr is linked with the main stator windings and the exciter field windings to provide closed loop control of the output voltage with load regulator of +/-1.0%.
In addition to being powered from the main stator,the avr also derives a sample voltage from the output windings for coltage control purposes.In response to this sample voltage,the avr controls the power fed to the exciter field,and hence the main field,to maintain the machine output voltage within the specified limits,compensating for load,speed,temperature and power factor of the generator.
Provision is made for the connection of a remote voltage trimmer,allowing the user fine control of generator's output.
Features
Technical specification | |
Sening input | |
Voltage |
Jumper selectable 100-130V ac 1 phase or |
190-264V ac 1 phase | |
Frenquency |
50-60Hz nominal |
