Help CenterCnc Wood Door Furniture Milling and Engraving Machine With Two Heads 2030
Related Products
-
Two Spindles CNC Stairs Handrail Chair Legs Processing MachineNegotiableMOQ: 1 Piece -
M25S Auto Tool Changing Cnc Router China Good Price 4-axis Wood Cnc RouterNegotiableMOQ: 1 Piece
-
CX-2025 With 8 Water Cooling Spindle Working at Same TimeUS$ 8,600 - 15,000MOQ: 1 Set
-
8 Heads 4 Axis Column Engraving MachineUS$ 18,000 - 26,000MOQ: 1 Set
-
Cylinder Statue Engraving MachineUS$ 8,000 - 17,000MOQ: 1 Set
Specifications
1.four heads work separately different tool2.imported square guide
3.servo motor inverter water cooling spindle
4.CE ISO
Advantage 1: Compared with CNC router with ATC, this machine is cheaper but high speed for exchanging tools.
Advantage 2: Easy to operate it.
Advantage 3: Two spindles with two different cutters, can work at the same time or separately, the efficiency can be increased up to twice if used at the same time,
Advantage 4: The distance of two heads can be adjusted freely, suitable for different sizes of material carving at the same.
Applicable mateiral: Wood, Red wood, MDF, Acrylic, Aluminium, PVC, Marble etc.
Standard Configuration:
- Whole Steel structure
- Imported linear square orbit
- Ball screw for Z axis, gear-wheel for X axis and Y axis
- U flash disk DSP control system
- Wentai Software and Type3 Software
- 4.5KW(imported bearing) water cooling spindle with diameter φ100
- Vacuum table with 6 zones separately control
- Water pump and dust collector system, dust cover, oiling system,
NO. |
Description |
Parameter |
2 |
X,Y working area |
2000*3000mm |
3 |
Z working area |
300mm |
4 |
Working accuracy |
0.05mm |
5 |
Repositioning accuracy |
0.05mm |
6 |
Machine Structure |
Whole Steel structure |
7 |
Table Type |
Vacuum and T slot table with water sink |
8 |
Max. traveling speed |
50000mm/min |
9 |
Max. working speed |
25000mm/min |
10 |
Interface |
USB |
11 |
Command |
G code*.u00*.mmg*. plt |
12 |
Surroundings for software |
windows98/2000/xp |
13 |
Working voltage |
3PH AC380V/50HZ |
14 |
Spindle power |
4.5KW Water cooled |
15 |
Spindle rotating speed |
0-24000rpm/min |
16 |
Drive Motor |
Stepper |
