Specifications
cnc router stone carving machine1.Adopt imported square orbit
2.adopt waterproof dustproof structure
3.Taiwan transducer
Chine high quality good price CX-9015 cnc router stone carving machine
Features:
1,X,Y,Z three-axis all the imported linear square orbit, two line sliding track, heavy loading, stable working,long lifetime.
2,X,Y,Z three-axis all have the waterproof, dustproof system, can prolong the life time of orbit and ball screw.
3, Water cooling constant torque spindle with the imported bearing, high power, low noise
4, Well compatibility, compatible with Type3/Artcam//Castmate/Wentai and many other software.
5, Double direction cutters cooling system can prolong the lifetime of cutters.
6, Full shielded, high flexility, uneasy distorted cable and imported electronic components the components guarantee
the stablitity of operating the machines.
7,,Taiwan transducer with stable output signals
8,Fully shieled,bending circuitry, and imported electronic components
9,Adopt imported ball screw
10,Cast iron structure, can load weight up to 200kg per meter square.
Application:
This series of models mainly used for lighter weight of the tile,bluestone ,marble,granite,white marble,sandstone,such as
a stone sculpture processing, category carved glass-cutting and engraving melting material.
Thechnical Specifications:
Performance parameter |
9015 |
1218 |
1224 |
X,Y Working area |
900mmx1500mm |
1200mmx1800mm |
1200mmx2400mm |
Z Working area |
250mm |
250mm |
250mm |
Table size |
1100mmx2000mm |
1400mmx2300mm |
1400mmx2900mm |
Processing precision |
0.05mm |
0.05mm |
0.05mm |
Reposition precision |
0.02mm |
0.05mm |
0.05mm |
Table structure |
aluminium |
aluminium |
aluminium |
X,Y,Z structure |
X,Y,Z ballscrew |
X,Y,Z ballscrew |
X,Y,Z ballscrew |
Command |
G CODE |
G CODE |
G CODE |
Machine power |
2KW |
2KW |
2KW |
Max processing speed |
6000mm/min |
6000mm/min |
6000mm/min |
Max speed |
8000mm/min |
8000mm/min |
8000mm/min |
Working voltage |
AC380V/50Hz |
AC380V/50Hz |
AC380V/50Hz |
Spindle power |
5.5KW |
5.5KW |
5.5KW |
Spindle rotating speed |
0-24000rpm/min |
0-24000rpm/min |
0-24000rpm/min |
Drive motor |
Stepper |
Stepper |
Stepper |
Operation system |
PCI CARD control |
PCI CARD control |
PCI CARD control |
Note: still other size models of this kind of machine, such as CX-1218, CX-1224 (the standard features
of these two models are the very same as CX-9015, just different in size).
The samples:
Our customers:
Our factory:
Our certification:
Further infos,pls do not hesitate to contact me,
hope to build cooperation with you.24hours service,
your inquiry will be replied very soon.
