Specifications
outdoor advertising equipment:1.imported top quality spare parts
2.stable quality and best after sale service
3.CE ISO
outdoor advertising equipment for small industries (cnc engraving machine) with CE
Features:
1. The cnc router adopts the mode of saving intermittence
2. Memory to ensure the processing point when the blade is broken or postpone situation
3. Specific saving mode of different points
4. X axis adopts popular dust-proof structure to make machine work for a long time
5. The large power cutting spindle does not only increase the fineness of engraving the breast card without screw and the under base is more flat and smooth. The machine is suitable for the architecture mould sign industry, school, enterprise, government to use
6. The super star cnc router can be widely used for architectural model, schools, companies and government
Technical parameter:
Model |
cx-3030 |
cx-6060 |
X Y working area |
300*300mm |
600*600mm |
Z working area |
Max 80mm |
Max 80mm |
Table size |
420*550mm |
600*600mm |
Max. rapid travel rate |
5-6m/min |
5-6m/min |
Max. working speed |
2-3m/min |
2-3m/min |
Max. feeding height |
80mm |
80mm |
Repositioning positioning accuracy |
0.05mm |
0.05mm |
Command language |
G-code, ugg,mmg,plt |
G-code, ugg,mmg,plt |
Max. power consumption(without spindle) |
300w |
300w |
Working voltage |
AC220V/50HZ |
AC220V/50HZ |
Spindle power motor |
1.5KW |
1.5KW |
Spindle speed |
0-24000rpm/min |
0-24000rpm/min |
Drive system |
stepper |
stepper |
Machine picture:
Engraving sample:
