Packaging & Delivery
| Packaging Details: | Standard Export package for CX-6090 cnc advertising machine on sales |
| Delivery Detail: | 15 days |
Specifications
CX-6090 cnc router cutting machine on sales
1.TAIWAN HIWIN ball screw
2.German ball screwsmall
3.CE&ISO c
Specification
art sign cutting plotter CX6090 1.stepper drive motor 2.
CX-6090 cnc advertising machine on sales
Feature:
1. using imported straight quadrated rail ,which imported from TaiWan.Two rows and four lines rolling block devices that ensure it is high loading capacity and moves steadily.the imported screw rod from Germany is very precise.
ftware has good compatibility and is compatible with several design software ,such as type 3/artcam/castmate/weitai and variety of CAD/CAM design software generate code which is processing.Ensure that the design barrier free.
3.has a power outage continued carving ,power failure recovery,processing time prediction function
Application:
1 . Furniture: plate, office furniture, doors, cabinets.
2 . Wood products: speakers, games cabinets, computer tables, sewing machines, musical instruments.
3 . Board processing: insulation, plastic chemical components, PCB, car body, bowling track, ABS, PP, PE, etc.
4 . Decoration: Acrylic, PVC, MDF, glass, plastic and soft metals such as copper and aluminum
Description |
Parameter :CX6090 |
X,Y,Z working area |
600x900x100-200mm |
X,Y,Z Traveling positioning accuracy |
±0.03/300mm |
X,Y,Z Repositioning positioning accuracy |
±0.03mm |
Lathe bed frame |
Steel square tubes |
X,Y Structure |
Rack drive, Taiwan HIWIN guide |
Z Structure |
Germany Ball screw and Taiwan HIWIN guide |
Drive motors |
Stepper system |
Table surface |
T-slot or vacuum table(T-slot vacuum table) |
Max power comsumption |
(without spindle)2.0KW |
Max rapid travel rate |
22000mm/min |
Max working speed |
15000mm/min |
Spindle power |
1.5KW(option) |
Spindle speed |
0-24000RPM |
Spindle inverter |
FoLinn inverter |
Working voltage |
AC220V/50/60Hz,3PH(Option:380V) |
Command language |
G Code |
Operatiing system |
DSP system (Nc studio/Mach3 PC software) |
Computer interface |
USB |
Flash memory |
128M(U Disk) |
Collet |
ER25(3.175/4/6/12.7mm. Optional ) |
X,Y Resolution |
<0.02mm |
Software compatiliby |
Type3/Artcam/Ncstudio/Ucancam/JDpaint etc software |
Running environment temperature |
0-45 centigrade |
Relative humidity |
30%-75% |
Packing size |
130*100*155cm |
N.W. |
500kg |
G.W. |
650kg |
Mini order quantity |
1 set |
warranty |
1 year |
Delivery time and payment |
7-30 days after get 30% payment by T/T(option:the third party alibaba ESCROW) |
Optional parts |
1.Air cooling spindle (HSD) or water cooling spindle 2.Taiwan Syntec system and Delta inverter 3.Japan Yaskawa/800w or Panasonic/750w servo motors 4.Vacuum pump(Germany Becker or chinese water and free oil pump) 5.Rotary system 6.Dust collector 7.Sink and water cooling system |
Quality Control |
1.Strect control machine assembly each link,ensure the machine clean and beautiful. 2.48 hours continuous work before the machine leave the factory, ensure high quality of the machine. |
After sales service |
1.24 hour technical support by email,calling or MSN 2.Uer-friendly english manual and vedio for machine using and maintaining. 3.Our machines obtain CE and ISO9001 certificate. |
Questions and answer:
Q1.how to get the most suitable machine and best price
please tell the material you want to working on ?
How to working on it ? Engraving ? Cutting ? Or other ?
What’s the MAX size of these material ?( length ? Width ? Thickness ?)
Q2: Do you have the manual of machine.
Yes,we have
Q3.If we donot know how to use the machine,can you teach us?
Yes,we will ,if you come to China,we will offer you free training until you can use machine freely.And if you are busy ,we will have the special engineer to your country,but you need to bear some fee,like tickets and hotel and meal.
Q4.How about your after-sales service?
we offer you 24 hours service phone,skype or MSN.
Q5.How about your guarantee period?
one year and during the time,if you have any questions ,we will solve it for free.
