TM1914 Double Data Line Addressable LED Strip

TM1914 Double Data Line Addressable LED Strip thumbnail-1
TM1914 Double Data Line Addressable LED Strip thumbnail-2
TM1914 Double Data Line Addressable LED Strip photo-1
TM1914 Double Data Line Addressable LED Strip photo-2
US$ 8.5 - 9.9 MOQ: 1 Meter
Key Specifications
Get Latest Price
LED Light Source:
SMD5050
Input Voltage(V):
DC5V
Color Temperature(CCT):
white
Contact Supplier Request Quote Chat Now
Shenzhen IPixel LED Light Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen baoan port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source SMD5050
Input Voltage(V) DC5V
Color Temperature(CCT) white
Working Temperature(℃) -40, 40
Working Lifetime(Hour) 50000
Lamp Body Material PVC
Certification CE
Emitting Color Changeable
Place of Origin Guangdong, China
Brand Name iPixel LED
Model Number s601914V5
Features

-It's double data cascade transmission,four PIN connection, address written needless but to resume broken transfer.
-Self detect the broken data loss,avoid the impact of some led breakdown.
-The C1C2 data verification to improve anti-jamming capability , a s a channel to detection and exclude the problems
in the production(Short ,off)
-The chip can systemize data and transfer it automatically, no signal attenuation even though long distance cascade.
-Tm1914 control circuit and the 8 pads RGB 5050 SMD led component TM1914D, to form a complete control of pixel.
Encapsulate with TM1914A-SOP8,then it’s compatible the PIN-TO-PIN. Cascading divider resistance to make led
DC5V-DC24V workable.



Details

3 pin inout

3 pin output



TM1914 Double Data Line addressable LED strip



compare



ws2812b 60 leds strip

TM1914 Double Data Line addressable LED strip

APA102 60leds strip



TM1914 Double Data Line addressable LED strip

parameter
Light source  Epistar5050SMD
Beam angel  120 deg
led quantity  60 leds /m
wattage  16w
size  5000*24mm
voltage  DC5v
Storage Temperature  -10-50

Packaging & Shipping

 TM1914 Double Data Line addressable LED strip
