Help CenterAffordable 4th Axis Cnc Router of Best Price With CE,ISO Certification Engraving Pillar
Related Products
-
4th Axis Cnc Router of Best Price With CE,ISO Certification Engraving PillarNegotiableMOQ: 1 Set -
Foam Industry Cutting Machine With Model 2550NegotiableMOQ: 1 Set
-
China CX-1530 High Gantry and 3d Foam Cutting MachineNegotiableMOQ: 1 Set
-
CX-1530 High Gantry and Hightened Z Axis Economic Foam Cutting MachineUS$ 10,000 - 18,000MOQ: 1 Set
-
Best Price Styrofoam Cutting Machine ChinaNegotiableMOQ: 1 Set
Technical Parameters of Wood cutting machine (4 Axis CNC router ) :
Description |
Parameter |
Models |
1325R /1224R/1318R |
Working Area (X*Y*Z) |
1220*2440*250mm/1200*2400mm*250mm/1300*1800mm*250mm |
Rotary Size |
40cm diameters, 130cm length |
Max Moving Speed |
30m/min |
Max Engraving Speed |
20m/min |
Positioning Accuracy |
0.05mm |
Hold mode |
Vacuum/Clamp (vacuum table, Vacuum pump) |
Option system |
Dust collector system, dust cover |
Spindle Speed |
0-24000rpm/min |
Spindle Power |
4.5kw water cooling (option: 3kw water cooling, 4.5kw /6kw air cooling) |
Tool Diameter |
2--12.7 |
Transmission |
X,Y Axis High Precision Rack Gears, Z Axis Ball Screw |
X,Y,Z Guide rail |
Linear Square Rail from Taiwan |
Control System |
DSP controller |
Driving |
Step motor (Option: Servo Motor) |
Software |
Ucancam / ArtCam/TYPE3 (Origional version) |
Command |
G Code (plt, mmg, uoo, bmp) |
Voltage |
AC380V/50-60Hz |
Gross Weight |
1200KG |
Net Weight |
1000KG |
Certificate |
ISO , CE test report |
Payment terms: T/T 30% in advance first, then the 70% after you receiving the copy of B/L of the shipment
Package: Strong plywood packages during the shipment
