VOXOA T40 Music hifi turntable 2016 Audio LP 2 Speed Belt Drive USB REC Turntable

Name: VOXOA T40 Music hifi turntable 2016 Audio LP 2 Speed Belt Drive USB REC Turntable
Brand: VOXOA
Price: USD $95 - 190 / Piece

FOB Price

USD $95 - $190 / Piece

5 Pieces(Min.Order)

Supply Ability 100 Piece / Pieces per Month
Port FOB HK
Payment Terms:Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

Guangdong, China

Brand Name:

VOXOA

Model Number:

VOXOA T40

Product Description

WARMLY WELCOME TO VOXOA HIFI WORD

VOXOA T40 TURNTABLE

VOXOA T40

Belt Drive Turntable with USB Rec

*2 SPEED BELT DRIVE TURNTABE – 33 AND 45 RPM

*USB AUDIO OUTPUT DIRECTLY CONNECT WITH PC ,NO NEED DRIVER

*BUILT IN PREAMPLIFIER (PHONO/LINE)

*AUDCITY RECORDING SOFTWARE INCLUDED

*PC MAC SYSTEM

*HIGH PRECISION MACHINING 330MM DIAMETER ALUMINUM PLATTER

*PITCH RANGE +/- 10%

*HEAVY STRUCTURE TILL 9 KG

*S SHAPE TONE ARM

*RUBBER CUSHION FEET

*ATTACHED DUST COVER AND CARTRIDGE (AT3600L)

Specification

Power : AC115/230V,50/60Hz

Consumption :14WATTS

Dimension:450mm(W)x352mm(D)x150mm(H)

Weight :9 Kg

Speed : 2 SPEED

Motor : DC MOTOR

Tracking Error Angle : Less than 3 degree

Anti-skating Range : 0~7g

Applicable Cartridge Weight : 3.5 ~8.5g

Audio Output :1.5~3.6mV at 1KHz 5cm/sec

Cartridge : AT-3600L

Frequency Response:20Hz~20KHz

Channel Separation :BIGGER THAN15dB

General Specification

1.GENERAL SECTION:

MODEL T40, Belt drive USB turntable

Power Supply AC 115/230,60/50Hz

Power Consumption 14W

Dimensions 450(W) x 350(D) x 150(H) mm

Weight 9 kg

2.STANDARD TEST CONDITION:

Ambient Temperature 23 ±2℃

Relative Humidity 65% ±5%

NOTE: Measurements can be carried out between 5℃ to 35℃ and 45% to 85% relative humidity.

3.TURNTABLE SECTION:

Type 2-speed full manual

Motor DC motor

Driving Method Belt drive

Turntable platter 332mm dia. Aluminum

Speeds 33-1/3 and 45 rpm

Wow and Flutter Less than 0.25% WRMS (JIS WTD) with 33-1/3 rpm

S/N ratio More than 50 dB (DIN-B)

Pitch Controls ±10%

Starting Time Less than 1 sec.

Breaking Time Less than 1 sec.

Time for speed change Less than 1 sec.

Speed tolerance at pitch=0 Within +3%,-2%

High of cue (first track) 8~10.5mm

Descend of cue 1~3 sec.

USB Function USB rec. Function

A/D, D/A 16BIT 44.1KHz or 48KHz USB SELECTABLE

Computer interface USB 1.1 Compliant WINDOWS XP, Vista or MAC OSX

4.TONEARM SECTION:

Type Static balanced S-shaped tonearm with detachable headshell

Effective Arm Length 230.5mm

Overhang 16mm

Tracking Error Angle Less than 3 degree

Tracking Force Adjustment range 3 – 4g (Cartridge: AT3600L)

Applicable cartridge weight 4 – 9g

Anti-skating range 0 – 7g

Phono Output Level 1.5~3.6 mV at 1KHz 5cm/sec (HP-4005)

Line Output Level 90~216mV at 1KHz 5cm/sec (HP-4005)

Frequency Response 20Hz-20KHz

Channel Separation More than 15dB

Channel Balance Within 2.5dB at 1KHz

5. EQ AMP

Output 150mV +/-4dB (IN: 2.5 mV 1KHz)

RIAA 20Hz~20KHz +1/-3dB (IN: 1.5 mV 1KHz)

6. ACCESSORIES SUPPLIED

Instruction Manual X 1

Dust Cover X 1

45 RPM Adaptor X 1

USB Cable X 1

2P RCA Cord X 1

Slipmat X 1

Headshell X 1

ann

el Balance: Within 2.5dB at 1KHz
