VOXOA T40 Portable Turntable Vinyl Record Player Gramophone With USB AUDIO Output

Shenzhen Wind-Walker Culture Communication Co., Ltd.
VOXOA T40 Portable Turntable Vinyl Record Player Gramophone With USB AUDIO Output thumbnail-1
VOXOA T40 Portable Turntable Vinyl Record Player Gramophone With USB AUDIO Output thumbnail-2
VOXOA T40 Portable Turntable Vinyl Record Player Gramophone With USB AUDIO Output thumbnail-3
VOXOA T40 Portable Turntable Vinyl Record Player Gramophone With USB AUDIO Output thumbnail-4
VOXOA T40 Portable Turntable Vinyl Record Player Gramophone With USB AUDIO Output thumbnail-5
VOXOA T40 Portable Turntable Vinyl Record Player Gramophone With USB AUDIO Output thumbnail-6
VOXOA T40 Portable Turntable Vinyl Record Player Gramophone With USB AUDIO Output photo-1
VOXOA T40 Portable Turntable Vinyl Record Player Gramophone With USB AUDIO Output photo-2
VOXOA T40 Portable Turntable Vinyl Record Player Gramophone With USB AUDIO Output photo-3
VOXOA T40 Portable Turntable Vinyl Record Player Gramophone With USB AUDIO Output photo-4
VOXOA T40 Portable Turntable Vinyl Record Player Gramophone With USB AUDIO Output photo-5
VOXOA T40 Portable Turntable Vinyl Record Player Gramophone With USB AUDIO Output photo-6
US$ 95 - 190 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
VOXOA
Model Number:
VOXOA T40
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB HK
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name VOXOA
Model Number VOXOA T40




 WARMLY WELCOME TO VOXOA HIFI WORD

                     VOXOA T40 TURNTABLE

 VOXOA T40

              Belt Drive Turntable with USB Rec

*2 SPEED BELT DRIVE TURNTABE – 33  AND 45 RPM

*USB AUDIO OUTPUT DIRECTLY CONNECT WITH PC ,NO NEED DRIVER

*BUILT IN PREAMPLIFIER (PHONO/LINE)

*AUDCITY RECORDING SOFTWARE INCLUDED

*PC MAC SYSTEM

*HIGH PRECISION MACHINING 330MM DIAMETER ALUMINUM PLATTER

*PITCH RANGE +/- 10%

*HEAVY STRUCTURE TILL 9 KG

*S SHAPE TONE ARM

*RUBBER CUSHION FEET

*ATTACHED DUST COVER AND CARTRIDGE (AT3600L)


 VOXOA T40 Portable turntable vinyl record player gramophone with USB AUDIO outputVOXOA T40 Portable turntable vinyl record player gramophone with USB AUDIO outputVOXOA T40 Portable turntable vinyl record player gramophone with USB AUDIO output

Specification



Power : AC115/230V,50/60Hz

Consumption :14WATTS

Dimension:450mm(W)x352mm(D)x150mm(H)

Weight :9 Kg

Speed : 2 SPEED

Motor : DC MOTOR

Tracking Error Angle : Less than 3 degree

Anti-skating Range : 0~7g

Applicable Cartridge Weight : 3.5 ~8.5g

Audio Output :1.5~3.6mV at 1KHz 5cm/sec

Cartridge : AT-3600L

Frequency Response:20Hz~20KHz

 VOXOA T40 Portable turntable vinyl record player gramophone with USB AUDIO output

VOXOA T40 Portable turntable vinyl record player gramophone with USB AUDIO outputVOXOA T40 Portable turntable vinyl record player gramophone with USB AUDIO outputVOXOA T40 Portable turntable vinyl record player gramophone with USB AUDIO outputVOXOA T40 Portable turntable vinyl record player gramophone with USB AUDIO outputVOXOA T40 Portable turntable vinyl record player gramophone with USB AUDIO outputVOXOA T40 Portable turntable vinyl record player gramophone with USB AUDIO output

Channel Separation :BIGGER THAN15dB



Ch

General Specification



1.GENERAL SECTION:



MODEL                          T40, Belt drive USB turntable



Power Supply                 AC 115/230,60/50Hz



Power Consumption      14W



Dimensions                    450(W) x 350(D) x 150(H) mm



Weight                           9 kg



2.STANDARD TEST CONDITION:



Ambient Temperature       23 ±2℃



Relative Humidity             65% ±5%



NOTE: Measurements can be carried out between 5℃ to 35℃ and 45% to 85% relative humidity.



3.TURNTABLE SECTION:



Type        2-speed full manual



Motor       DC motor



Driving Method         Belt drive



Turntable platter       332mm dia. Aluminum



Speeds            33-1/3 and 45 rpm



Wow and Flutter      Less than 0.25% WRMS (JIS WTD) with 33-1/3 rpm



S/N ratio     More than 50 dB (DIN-B)



Pitch Controls      ±10%



Starting Time     Less than 1 sec.



Breaking Time    Less than 1 sec.



Time for speed change      Less than 1 sec.



Speed tolerance at pitch=0      Within +3%,-2%



High of cue (first track)         8~10.5mm



Descend of cue      1~3 sec.



USB Function        USB rec. Function



A/D, D/A        16BIT 44.1KHz or 48KHz USB SELECTABLE



Computer interface     USB 1.1 Compliant WINDOWS XP, Vista or MAC OSX



4.TONEARM SECTION:



Type      Static balanced S-shaped tonearm with detachable headshell



Effective Arm Length    230.5mm



Overhang    16mm



Tracking Error Angle    Less than 3 degree



Tracking Force Adjustment range      3 – 4g (Cartridge: AT3600L)



Applicable cartridge weight    4 – 9g



Anti-skating range     0 – 7g



Phono Output Level     1.5~3.6 mV at 1KHz 5cm/sec (HP-4005)



Line Output Level       90~216mV at 1KHz 5cm/sec (HP-4005)



Frequency Response     20Hz-20KHz



Channel Separation    More than 15dB



Channel Balance    Within 2.5dB at 1KHz



5. EQ AMP



Output     150mV +/-4dB (IN: 2.5 mV 1KHz)



RIAA    20Hz~20KHz +1/-3dB (IN: 1.5 mV 1KHz)



6. ACCESSORIES SUPPLIED



Instruction Manual X 1



Dust Cover X 1



45 RPM Adaptor X 1



USB Cable X 1



2P RCA Cord X 1



Slipmat X 1



Headshell X 1

ann

el Balance: Within 2.5dB at 1KHz

VOXOA T40 Portable turntable vinyl record player gramophone with USB AUDIO output
