1. Describe of JS500
JS750 concrete mixer can mix the plastic and half-dry hard concrete,fluid concrete and light aggregate concrete. It is applicable to the common construction working site, road, bridge and each kind of precast product factory. It can work independently or be used as facility concrete plant, which is applied with correspond batching machine. JS750 has manul or Hydraulic pressure discharge mode. It has reasonable instructure,high production efficiency,drive, reposefully and low noise .The electrical system adopts import component, which is good performance and reliability.
2.Technology Parameters:
| Type | JS500 |
| Capacity of material --IN(L) | 800 |
| Capacity of material --OUT(L) | 500 |
| Productivity(m3/h) | ≥25 |
| Maximum diameter of / Cobble | 80 |
| Bone material (mm) /Crushed stones | 60 |
| Mixing fan / Turning speed(r/min) | 35 |
| / Quantity | 2*7 |
| Mixing engine / Type | Y180M-4 |
| / Power(kw) | 18.5 |
| Mixing engine /Type | YEZ132S-4-B5 |
| / Power(kw) | 5.5 |
| Pump / Type | 50DWB20-8A |
| / Power(kw) | 0.75 |
| Hosting speed of material holder | 18 |
| Outside size(mm) / Transport state | 3050*2300*2680mm |
| / Working state | 4461*3050*5225mm |
| Weight (kg) |
4000 |
3.Pictures of JS500
4,Details of product
1).The stand concrete mixer is the advanced, ideal type at home and abroad. Good mixing quality, high automation and efficiency, low energy consumption and noise as well as easy operation are the advantages of it.
2).Besides, it also has the strengths of high speed of discharging, long service life of liner and blades and easy maintenance.
3)Applies for the mix of plastic concrete, dry concrete, light weight aggregate concrete and different mortars.
4).Mtorized discharge port is applied in the machine, which makes it could be matched with dump car.
5).So it is the ideal machine for construction site and prefabrication.
5.Block making production line
6.Workshop and product display
7.Customer Visit
8,Packing and Shipping
9.Our Service
Our company has product with reliable performance, have after-sale service team with rich experience of block machine and paverment block machine. We follow the tides closely; the internet technology is applied to every process of producing and operation. We supply the latest product information and technical service through internet activity. We believe you not only need a product but also good after-sale service. We not only value technology and quality of the product, also we are willing to supply service with comfortable, convenient, assured and carefree.
Before Sales
1. Guide our customers to deploy the most useful equipment item according to their requirement.
2. Provide technical data, including equipment bill, layout, base specification and installation picture for reference.
3. Design and manufacture product according to the customers' special requirement.
4. Dispatch the technical person to reach the locale to layout field, design the best installation flow and scheme for reference for free.
During Sales
1. Manufacturing product according to the technology standard strictly.
2. Test the machine according to relevant stipulate of the equipment.
3. Verify the product strictly after manufacturing complete.
4. Delivery according to the contract.
After Sales
1. Dispatch special after-sales service staff to help customer install and adjust the machine, trial run and train the operator on the site.
2. Warranty policy: three guarantees of quality, the product will be guarantee for 1 year (except wearing part). The service life of the machine depends on maintenance. We will repair the machine for free when meet equipment trouble during the warranty period meanwhile customer maintenance the machine according the operation procedure. We will supply lifelong maintenance guide, also we will timely solve all problems the operator meet during operation.
10.Related products
11.Why choos us
If you are interested in our JS series mixer, please contact me :
SKype:live:kevinshangfinder
TEL / VIBER: +86 15060641046
