High Strength Oval Tube,top Quality Oval Tube Manufacturer
US$ 0.25 - 5
MOQ: 3000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
VIC
Model Number:
FRP Tube
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Strength Heat Insulation Tube,top Quality Heat Insulation Tube ManufacturerUS$ 0.25 - 5MOQ: 3000 Meters -
High Strength Fiber Reinforced Plastic Tube,top Quality Fiber Reinforced Plastic Tube ManufacturerUS$ 0.25 - 5MOQ: 3000 Meters
-
FRP Garden Pipes, Outdoor BarsNegotiableMOQ: 500 Meters
-
FRP TubeUS$ 0.01 - 2MOQ: 500 Meters
-
Glass Fiber Pipe, Professional Manufacturers, High-Strength Glass Fiber PipeUS$ 1 - 100MOQ: 500 Meters
Place of Origin
Jiangsu, China
Brand Name
VIC
Model Number
FRP Tube
Application
Infrastructure, construction,cooling tower,bridge,farming,etc.
Surface Treatment
Smooth surface
Technique
Pultrusion
Dimensions
5mm-100mm,pls check the specification sheet
Product Description
Fiberglass tube,FRP tube,oval tube
oval tube are made through pultrusion process. During the pultrusion process, the raw materials are pulled through a heated steel forming die using a continuous pulling device.oval tube are made of different resins reinforced with fiberglass by pultrusion technology.oval tube are widely used in many areas.
Features of oval tube:
Lightweight. The density of fiberglass rod is about 1.6-2.1g/cm3,which make it is lighter than metal rods.
- Corrosion Resistant
- Low Conductivity - Thermally and Electrically
- Non-Magnetic - Electromagnetic Transparency
- Dimensional Stability
- Low Maintenance
- High Mechanical Strength
- UV & Corrosion Resistant
- Outstanding Electrical Insulation Capability for Low- and Medium-Voltage
- Heat Resistance
- Abrasion and Impact Resistance
- Good Machinability
- Longevity. These fiberglass stakes will last for 25 years or more, being rugged, flexible and corrosion/rot proof.
Detailed Images
We can supply series of oval tube with different sizes and color:
Specification sheet
Below is a partial list of readily available sizes with fiberglass rods. Customized sizes to meet the specific needs of any customer can be determined by that customer alone or in consultation with VIC
| Round Tube |
|
||||||||||||
| mm | inch | Weight/Material Length | |||||||||||
| OD | ID | Thickness | OD | ID | Thickness | g/m | lb/ft | ||||||
| 4 | 2 | 1 | 0.157 | 0.079 | 0.039 | 19 | 0.013 | ||||||
| 5 | 3 | 1 | 0.197 | 0.118 | 0.039 | 25 | 0.017 | ||||||
| 6 | 3 | 1.5 | 0.236 | 0.118 | 0.059 | 42 | 0.028 | ||||||
| 6 | 4 | 1 | 0.236 | 0.157 | 0.039 | 31 | 0.021 | ||||||
| 6.5 | 3 | 1.75 | 0.256 | 0.118 | 0.069 | 52 | 0.035 | ||||||
| 6.5 | 4 | 1.25 | 0.256 | 0.157 | 0.049 | 41 | 0.028 | ||||||
| 7 | 4 | 1.5 | 0.276 | 0.157 | 0.059 | 52 | 0.035 | ||||||
| 7 | 3 | 2 | 0.276 | 0.118 | 0.079 | 63 | 0.042 | ||||||
| 8 | 5 | 1.5 | 0.315 | 0.197 | 0.059 | 61 | 0.041 | ||||||
| 8 | 4 | 2 | 0.315 | 0.157 | 0.079 | 75 | 0.051 | ||||||
| 8.5 | 4 | 2.25 | 0.335 | 0.157 | 0.089 | 88 | 0.059 | ||||||
| 9 | 5 | 2 | 0.354 | 0.197 | 0.079 | 88 | 0.059 | ||||||
| 9.5 | 5 | 2.25 | 0.374 | 0.197 | 0.089 | 102 | 0.069 | ||||||
| 10 | 6 | 2 | 0.394 | 0.236 | 0.079 | 101 | 0.068 | ||||||
| 11 | 7 | 2 | 0.433 | 0.276 | 0.079 | 113 | 0.076 | ||||||
| 12 | 8 | 2 | 0.472 | 0.315 | 0.079 | 126 | 0.084 | ||||||
| 12.7 | 8 | 2.35 | 0.500 | 0.315 | 0.093 | 153 | 0.103 | ||||||
| 14 | 10 | 2 | 0.551 | 0.394 | 0.079 | 151 | 0.101 | ||||||
| 15 | 10.5 | 2.25 | 0.591 | 0.413 | 0.089 | 180 | 0.121 | ||||||
| 16 | 12 | 2 | 0.630 | 0.472 | 0.079 | 176 | 0.118 | ||||||
| 18 | 13 | 2.5 | 0.709 | 0.512 | 0.098 | 243 | 0.164 | ||||||
| 19 | 14.5 | 2.25 | 0.748 | 0.571 | 0.089 | 237 | 0.159 | ||||||
| 20 | 15 | 2.5 | 0.787 | 0.591 | 0.098 | 275 | 0.185 | ||||||
| 22 | 16 | 3 | 0.866 | 0.630 | 0.118 | 358 | 0.241 | ||||||
| 24 | 18 | 3 | 0.945 | 0.709 | 0.118 | 396 | 0.266 | ||||||
| 25 | 20 | 2.5 | 0.984 | 0.787 | 0.098 | 353 | 0.237 | ||||||
| 25.4 | 20 | 2.7 | 1.000 | 0.787 | 0.106 | 385 | 0.259 | ||||||
| 26 | 20 | 3 | 1.024 | 0.787 | 0.118 | 434 | 0.291 | ||||||
| 28 | 24 | 2 | 1.102 | 0.945 | 0.079 | 327 | 0.220 | ||||||
| 30 | 25 | 2.5 | 1.181 | 0.984 | 0.098 | 432 | 0.290 | ||||||
| 32 | 27 | 2.5 | 1.260 | 1.063 | 0.098 | 463 | 0.311 | ||||||
| 35 | 30 | 2.5 | 1.378 | 1.181 | 0.098 | 511 | 0.343 | ||||||
| 38 | 30 | 4 | 1.496 | 1.181 | 0.157 | 855 | 0.574 | ||||||
| 40 | 30 | 5 | 1.575 | 1.181 | 0.197 | 1100 | 0.739 | ||||||
| 40 | 32 | 4 | 1.575 | 1.260 | 0.157 | 905 | 0.608 | ||||||
| 40 | 35 | 2.5 | 1.575 | 1.378 | 0.098 | 589 | 0.396 | ||||||
| 50 | 44 | 3 | 1.969 | 1.732 | 0.118 | 886 | 0.595 | ||||||
| 50.8 | 44 | 3.4 | 2.000 | 1.732 | 0.134 | 1013 | 0.680 | ||||||
| 76 | 70 | 3 | 2.992 | 2.756 | 0.118 | 1376 | 0.925 | ||||||
| 100 | 95 | 2.5 | 3.937 | 3.740 | 0.098 | 1532 | 1.029 | ||||||
| 100 | 93 | 3.5 | 3.937 | 3.661 | 0.138 | 2122 | 1.426 | ||||||
Tips:
- If you can‘t find the sizes you need,please feel free to contact VIC.
- Any lengthes and colors are based on your requirements
- Customized shapes are welcome
Quality Control
We supply high quality products with reasonable price
Packaging & Shipping
Packing:plastic film,carton box,wood box,pallet,etc.Customized packing are welcome.
Aplication
fiberglass tubes are widly used in many fileds,such as:
Company Information
Nanjing VIC Advanced Materials Co. ,LTD. is an innovative enterprise specializing in carbon fiber%glass fiber composite materials and other composites. After years of development ,VIC Advanced Materials Company has become one of leading manufacturers of carbon fiber composite materials in our country. With our principle of ingenuity, and responsiveness empowers us to fulfill our key mission that make our clients satisfied, we win our clients from worldwide such as USA, UK, Australia, Pakistan etc.
