Help CenterHigh Quality Ultrasonic Fuel Sensor for Truck FleetTruck Anti Fuel Theft,fuel Level MonitoringNon Contact Fuel Level Sensor
Related Products
-
Non Contact Fuel Level Sensor for Fuel Consumption MonitorFuel Tank Level MonitoringUltrasonic Fuel and Liquid Level SensorUS$ 87.07 - 98.68MOQ: 100 Sets -
Fuel Level Sensor for Vehicle,truck,taxi,carFuel Tank Level MonitoringUltrasoniliquid Level SensorUltrasonic Fuel Level DetectorUS$ 69.95 - 98.68MOQ: 1000 Sets
-
Truck Anti Fuel Theft Fuel Level MonitoringFuel Tank Level SensorUltrasonic Fuel Level Measurement for Fuel Consumption ControlUS$ 100 - 200MOQ: 2 Sets
-
Ultrasonic Diesel Fuel Tank Level Sensor With RS232,RS485,1-5V and 4-20mA Output for VehicleSensorsFuel Tank Level MonitoringUS$ 100 - 200MOQ: 1 Set
-
Ultrasonic Sensors Level for Diesel Fuel Anti TheftVehicle Fuel Level Sensor Tank Fuel / Water Level Sensor With GPS InterfaceUS$ 66.35 - 98.68MOQ: 2000 Sets
This product is with the feature of high accuracy, wide range operating voltage (DC9-36V), four types output modes (voltage output , current output, RS232 and RS485), it is also with alarm output and easy to install(outer ashering, no need punch).
Features:
1) Measuring precision, measurement resolution is 0.1mm, liquid level measurement accuracy is 0.5%.
2) Good stability; 3) Easy to install; 4) Simple application; 5) Strong antistatic ability (EMC);
6) Variety of standard signal output ways, which are analog voltage (1-5V) and current (4-20mA), digital output RS232 and RS485;
Technical parameters:
Ultrasonic liquid level detector | ||
Operating Voltage |
DC9V-36V |
|
The power supply ripple |
Less than 100mV |
|
Operating current |
Less than 55mA |
|
Measuring distance |
4cm to 100cm; pressure-bearing range: -0.1MPa~32MPa |
|
Resolution |
0.1mm |
|
Measurement accuracy |
0.5% |
|
Temperature compensation range |
-40 - +80°C |
|
Output mode |
analog voltage,current,RS485,RS232 |
|
Analog output |
Voltage output (default) |
1-5V (corresponding 0-100cm) |
Current output |
4-20mA (corresponding 0-100cm) |
|
Digital output |
RS232(default) |
See the “communication protocol” |
RS485 | ||
Alarm output |
need external connection a alarming horn to achieve alarm |
|
Install method |
bottom of fuel tank/can, water tank |
|
Operating temperature |
-40 - +80°C |
|
Storage temperature |
-50 - +100°C |
|
Size |
102*48*25mm with mounting holes |
|
Ultrasonic transducer | ||
Operating temperature |
-40 - +80°C |
|
IP grade |
IP66 |
|
Cable length |
5m and with shield |
|
Weight |
About 770g |
|
