Specifications
Automatic Welding Machine1.Similar Products:Box Beam, C Channel Steel
2.Finished Product:H / I Beam / Other Profile Steel
LHC Single Cantilever type Welding Machine:
LHC cantilever submerged arc welding machine is used for heavy steel production line and super high H-beam submerged arc welding.The machine structure is cantilever arm table driven type.The machine is composed of working table travel device,cantilever frame,welding arm elevator,horizontal travel device,arc guide device,flux recovery system,automatic submerged arc welding system,electrical control system and etc.The frequency conversion motor driving system,drags the working table move as a unit,drives the guide arc device.The spring extension device make the guide arc device to force guide arc wheel working along the boat shaped seam.Flux recovery system effectively recover,separate used flux,and eliminate useless slag.It can ensure safe reuse of the flux.
SXBH Double Cantilever type Welding Machine:
SXBH double-cantilever submerged arc welding machine is widely used in large steel structure enterprises and have received a hot of praise from customers.It is mainly for large size steel structure welding,The one arm next to the wall can weld workpiece shorter than 1.8m.While the other one have no limit of the height of work-piece.Only to raise the welding platform supporting frame can make it the right position of working.
Model |
web height mm |
flange width mm |
welder model |
welding type |
welding speed |
welding torch return speed |
rails' distance |
overall power |
LHA-4000 |
200-1500 |
200-800 |
MZ- 1000 2pcs |
boat-type welding |
0.15-1.5m/min |
3m/min |
4000mm |
10KW,exclude welder power |
SXBH-20 |
200-2000 |
200-800 |
2000mm |
equipment quality promise:
1, the Company's manufacturing facilities are applicable to the relevant national standards and enterprise standards.
2, the company's products are manufactured to meet the technical requirements and parameters should be listed in the specification and to ensure safety and reliability.
3, the company may send engineers to the demand-side participation to help guidance of installation and commissioning of equipment until the machine is qualified and can be put into use. Also we can help the demand side with training equipment operators and maintenance personnel. (Note: The installation and commissioning of equipment abroad, we will take cost in accordance with the cost of a standard international practice)
4 Equipment has 1 year warranty, during the warranty period, the company can track service and maintenance.
Our services:
1.Oversea engineers:
We provide oriented after-sales service including the oversea engineers tranning available and also international dealer center for any emergency guidance.We have established worldwide network to guarantee our timely response for your any demand no matter where you are.
2.Learning trip:
We welcome engineers from your side to learn the technical design and normal maintenance here, this will help you easyly to understanding.
3.English Manual:
We have Mannual to show you along with the machine.So you can learn this from the existing document to deeper your knowledge and understanding.
4.Face to face to teacing:
Through internet video face to face for machine teaching,because of the high development in internet,the world has become smaller and you can easy contact us if any assistance needed.
5.Through all the ways,we will guarantee the service quality and ensure you will be well helped anything anywhere.
Our company:
Jiangsu Yaoqiang Technical Group is a dealers holding type and high-tech enterprise. It mainly supply welding, cutting, milling, pipe producing production line as well as electrical automation equipment. The group consists of Jiangsu Silver Coast International Trading Development Co., Ltd (locate in Wuxi)& Dongtai Yaoqiang Mechinery Manufacture Co., Ltd. While Wuxi company, which is located in National technical industry park, i. e.The Wuxi Liando U Valley, besides the Taihu lake with beautiful scenery and renowned humanities, is mainly focus on enterprise blue print, R&D, marketing,trading, management
and finance. The Dongtai plant is devoted to technics, manufacture, process control, test and after-service, which locates at Dongtai Tangyang Xinhong Machinery industry park, in the wet land area off the seashore of Huanghai.
So we are manufacturer and trader. The Wuxi part is for trading and Dongtai part is forproducing.
Here we make a promise to you all: we will offer you the products with the ideal price and good quality.
If you have any problems or you are interested in our products, Please contact me via Email or following ways:
Skype:Sakina135246
QQ:2696243358
Tel:0086-15061825918
