Features:
1) High degree of protection;
2) Wide usage range, low-power dissipation;
3) Simple to use, handle easily;
4) High measuring accuracy and resolution;
5) Small detection blind area, long detection range;
6) With high precision temperature output and temperature compensation function;
7) Varied output mode: serial output, PWM output, digital output;
Applications:
1) High precision distance measuring;
2) Obstacle-avoidance, automatic control;
3) Objects close to, exist, perceive;
4) Traffic control;
5) Security and protection, industrial control;
6) Artificial intelligence, teaching and research;
Electrical parameters:
|
PWM output |
Serial output |
Digital output |
||
Supply voltage |
DC3.3V-12V, ripple wave is less than 100mV |
||||
Standby current |
Less than 200uA |
Less than 400uA |
|||
Operating current |
Supply voltage is 5V, cycle is 250MS, average current is 2mA |
||||
Center frequency |
40 KHz |
||||
Blind zone |
250 mm |
||||
Start detection |
Need to subtract 40mm (the distance from surface of ultrasonic transducer to the plane of horn mouth) |
||||
Max. detection distance |
More than 8000 mm |
||||
Emission angle |
8° |
||||
Work cycle |
More than 60MS |
250 MS |
|||
Trigger signal |
Falling edge trigger |
GND connection |
|||
Test precision |
±1CM |
||||
Resolution of ranging |
1 MM |
||||
Temperature compensation |
Non compensation |
compensation |
|||
Temperature output |
None |
Have |
None |
||
Operating temperature |
-25℃—70℃ |
||||
Storage temperature |
-40℃—85℃ |
||||
