Home > Products > Welding Machine > Cheap SAW Double Cantilever Model Welding Machine
Cheap SAW Double Cantilever Model Welding Machine
- 5 Piece / Pieces per Month
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | YQ(YaoQiang) |
Model Number: | LHA-4000,SXBH-20 | Arc Current: | 1000A | Pulse Frequency: | customized |
Pilot Arc Current: | customized | Rated Duty Cycle: | 100% | Motor Type: | AC Motor |
Dimensions: | Customized | Usage: | I/H-beam steel welding | Voltage: | 220V to 480V / Customized |
Power(W): | 10W(Except Welder) | Certification: | ISO,SGS,CE | Warranty: | 12Months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
YQ Cheap SAW Double Cantilever Model Welding Machine
Specification:
LHC Single Cantilever type Welding Machine:
LHC cantilever submerged arc welding machine is used for heavy steel production line and super high H-beam submerged arc welding.The machine structure is cantilever arm table driven type.The machine is composed of working table travel device,cantilever frame,welding arm elevator,horizontal travel device,arc guide device,flux recovery system,automatic submerged arc welding system,electrical control system and etc.The frequency conversion motor driving system,drags the working table move as a unit,drives the guide arc device.The spring extension device make the guide arc device to force guide arc wheel working along the boat shaped seam.Flux recovery system effectively recover,separate used flux,and eliminate useless slag.It can ensure safe reuse of the flux.
SXBH Double Cantilever type Welding Machine:
SXBH double-cantilever submerged arc welding machine is widely used in large steel structure enterprises and have received a hot of praise from customers.It is mainly for large size steel structure welding,The one arm next to the wall can weld workpiece shorter than 1.8m.While the other one have no limit of the height of work-piece.Only to raise the welding platform supporting frame can make it the right position of working.
Model | web height mm | flange width mm | welder model | welding type | welding speed | welding torch return speed | rails' distance | overall power |
LHA-4000 | 200-1500 | 200-800 | MZ- 1000 2pcs | boat-type welding | 0.15-1.5m/min | 3m/min | 4000mm | 10KW,exclude welder power |
SXBH-20 | 200-2000 | 200-800 | 2000mm |
Our Service--We Cherish Every Order From Every Customer
Punctual delivery time:
•We put your order into our tight production schedule, ensure your punctual delivery time.
•Production / inspection report before your order packed.
•Shipping notice/ insurance to you as soon as your order is shipped.
Pre-sales service:
•We value every inquiry sent to us, ensure quick competitive offer within 12 hours.
•We cooperate with customer to design and develop the new products. Provide all necessary document.
•We are a sales team, with all technical support from engineer team.
After sales service:
•We respect your feed back after receive the goods.
•We provide 12-24 months warranty after goods arrive.
•We promise all spare parts available in lifetime use.
•We lorge your complain within 48 hours.
Trade Assurance:
Packaging & Delivery:
Packaging Details:Standard export package
Delivery Details: Within 15 days after received your deposit
Company Show:
Company Honor:
Transaction Process:
Sales Network:
FAQ:
1. Are you factory or foreign trade company?
We have our own factory, We are industry and trade integration.
2. Where is your factory located? How can I visit there?
Our factory is located in Dongtai City, Jiangsu Province, one hour train from Shanghai.All our clients, from home or abroad, are warmly welcome to visit us!
3. What's the quality of your products?
We are very focused on the quality of the products, good quality products can bring us more customers, so, All spare parts of this machine come with best brand and best quality, after completing the installation we will test the machine for 48 hours, also we can provide the machine's working video before shipping.
4. What shall we do if don't know how to operate your machine after bought from you?
We have detailed installation and operating instructions attached, also comes with video, it is very simple. We have telephone and email support at 24 hours a day.
5. What to do if the machine has a problem?
24 hours timely response of mail and phone calls. If the parts broken belong to non-artificial factors within 12 months, we offer free replacement. If beyond 12 months, customers should bear the freight back and forth and accessories cost.
6. What other things also need after we bought your machines?
(1) With flame cutting: you just need to access to oxygen and fuel gas. (2) With plasma cutting: need plasma power source and air compressor. You can match plasma power supply by yourself, or buy together with the cutter from us, it's optional. If you buy from us, we will connect the wires of plasma power source and CNC cutting machine together, then more conveniently to use.
7. How can I know more about the machine?
We are honored to send you some pictures and vedio about our machine. And we welcome every customer visit our factory.
8. How does your factory do regarding quality control?
Quality is priority. Factory director always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained ZDHY, ISO9001 authentication.
9. What are your payment terms?
We support T/T, L/C, Western Union and so on. Other ways can also be received after we both sides discussion and agreement. Any other questions contact us directly!
