Temperature and Humidity Sensor Module
US$ 2.9 - 5
/ Piece
1 Piece(Min. Order)
- ShenZhen
- Money Gram Credit Card
You May Like
-
Temperature and Humidity Sensor Module
-
Digital Temperature and Humidity ControllerTemperature and Humidity SensorMODBUS Temperature Humidity TransmitterSensors
-
Intelligent Temperature and Humidity TransmitterDigital Temperature and Humidity ControllerRS - 485 Temperature Humidity Sensor
-
Temperature and Humidity Controller Digital Temperature and Humidity MonitorVoltage Source Temperature and HumidityTransmitter
-
Current Mode Temperature and Humidity TransmitterTemperature and Relative Humidity Sensor4-20mA Temperature Humidity Sensors
-
Intelligent Temperature and Humidity TransmitterHumidity and Temperature MonitorSensorsRS232 Temperature and Humidity Sensor
Product Details
| Place of Origin | Guangdong, China | Brand Name | DYP | |
| Model Number | DYP-TH02A | Usage | Other, Temperature and Humidity Sensor | |
| Theory | Other, Temperature and Humidity Sensor | Output | Digital Sensor |
Product Description
Specifications
Single interface port digital sensor module,suitable for environmental testing, HVAC applications, etcFeature:
1 High accuracy;
2 High data transferring rate;
3 Single interface port digital sensor module;
4 Suitable for environment testing, HVAC applications, etc.;
5 Size: Approx. 18 x 12mm;
Parameter:
1 Humidity Resolution: Max. 1%;
2 Repeatability: 1% (typical value);
3 Accuracy Uncertainty: 3% (typical value); Max. 5% (Temperature at 0 - 50°C);
4 Interchangeability: Fully interchangeable;
5 Nonlinearity: 1% (typical value);
6 Humidity Range: Min. 10%; Max. 98% (Temperature at 0°C - 50°C);
7 Response Time: 60 seconds (typical value);
8 Long Term Stability: Typically 2% / yr (Non-condensate);
9 Temperature Resolution: 0.1°C (typical value);
10 Repeatability: 0.1°C (typical value), Max. 0.2°C;
11 Temperature Range: Min. -40 °C; Max. 70 °C;
12 Accuracy: ±0.5 °C (typical value); Max .± 1.0 °C;
13 Response Time: 60 seconds (delta T=1.0);
