Help CenterPIR Infrared Pyroelectric Motion Sensor Detector Module DYP-ME003Adjustable IR Pyroelectric Infrared PIR Motion Sensor Detector
Related Products
-
High Accuracy PIR Infrared Pyroelectric Motion Sensor SwitchIR Pyroelectric Infrared PIR Motion Sensor Switch With Black LensUS$ 4.28 - 4.95MOQ: 100 Pieces -
DC4.5-20V PIR Infrared Pyroelectric Motion Sensor Switch With Black LensIR Pyroelectric Infrared PIR Motion Sensor SwitchUS$ 3.79 - 4.12MOQ: 500 Pieces
-
DYP-ME003 Adjustable IR Pyroelectric Infrared PIR Motion Sensor Detector Module With Black LensPIR Motion Sensor Detector ModuleUS$ 1.98 - 2.47MOQ: 500 Pieces
-
IR Pyroelectric Infrared PIR Motion Sensor Detector Module With Black LensPIR Infrared Pyroelectri Motion Sensor Detector ModuleUS$ 2.25 - 2.47MOQ: 100 Pieces
-
IR Pyroelectric Infrared PIR Motion Sensor Switch With Black LensDC4.5-20VPIR Infrared Pyroelectri Motion Sensor SwitchUS$ 6.58 - 8MOQ: 10 Pieces
This PIR Motion Detection Sensor Module is consists of pyroelectric sensor and fresnel lens that detects motion by measuring change in the infrared levels emitted by the objects. It can detect motion up to 20ft. This module is very sensitive to change in infrared levels subjected by human movement.
Features:
1) Infrared sensor with control circuit board.
2) The sensitivity and holding time can be adjusted.
3) Small and light, it is easy to use.
4) Detecting distance is up to 7m.
5) Suitable for the field of security, toy, automation control etc.
Specifications:
1) Working voltage: DC 4.5V--20V;
2) Quiescent Current: Less than 60uA;
3) Voltage output: High/Low level signal:3.3V TTL output;
4) Detection distance: 3--7M(can be adjuted);
5) Detection angle: <110degree;
6) Delay time: 5-200S (can be adjuted, default 5s +-3%);
7) Blockade time: 2.5S (default);
8) Trigger method: L: unrepeatable trigger H: repeatable trigger(default);
9) Photosensitive setting: Use CDS (Defaut: included, not welded);
10) Working temperature: -20---+80degree;
11) Product weight: 6.4g;
12) Product size: 3.2 * 2.4 * 2.4cm;
