There are four signal output interfaces, which are high-low level output interface, NPN and PNP output interface, RS485 interface, which corresponding item number are:
1) high-low level output interface --- item number: DYP-Y25-V;
2) NPN output interface --- item number: DYP-Y25-NPN;
3) PNP output interface --- item number: DYP-Y25-PNP;
4) RS485 interface --- item number: DYP-Y25-RS485;
Could choose any one of them only !!!!
Parameters:
Name | Parameters |
Input voltage(InVCC) | DC 5~24 V |
Power consumption | 5mA |
Output voltage (high level) | InVCC |
Output voltage (low level) | 0V |
Output current | 1~100mA |
Response time | 500mS |
Working temperature | 0~65℃ |
The thickness range of induction(sensitivity) | 0~7 mm |
Communication | RS485 |
Humidity | 5%~100% |
Material | ABS |
Waterproof performance | IP67 |
More details please feel free to contact us!!!
