Wireless Parking Lot DetectorCar Parking Sensor SystemSmart Parking SystemParking Guidance SensWireless Vehicle Detection Sensor

Specifications

Works with parking sensor led sign, guides drivers to find parking space and with feature of high accurancy, easy installation.

 Technical parameters:



Detector:



1) Operating voltage: DC 12V ;

2) Voltage ripple requirements:   Less than 100mV;

3) Peak current: 100mA;

4) Max.  power consumption: 1.2W;

5) Operating temperature: -20 - 70°C;

6) Storage temperature: -30 - 80°C;

7) RF frequency band: ISM 2.4 ~ 2.5GHz;

8) Blind zone: Less than 40 cm;

9) Maximum distance: 5m;

10) Range error: Less than 5% ;

11)  Detection degree: 16 °;

12) Detection period: 3s - 6s;



Concentrator:



1) Operating voltage: DC 12V ;



2) Voltage ripple requirements:   Less than 100mV;



3) Peak current: 200mA;



4) Max.  power consumption: 2.4W;



5) Operating temperature: -20 - 70°C;



6) Storage temperature: -30 - 80°C;



7) RF frequency band: ISM 2.4 ~ 2.5GHz;



Repeater:





1) Operating voltage: DC 12V ;







2) Voltage ripple requirements:   Less than 100mV;







3) Peak current: 35mA;







4) Max.  power consumption: 0.42W;







5) Operating temperature: -20 - 70°C;







6) Storage temperature: -30 - 80°C;







7) RF frequency band: ISM 2.4 ~ 2.5GHz;
