Specifications

DYP-ME001A-KG is an intelligent non-contact switch. This infrared sensor is used for intelligent faucet,urinal,sanitary ware and more.

Features:

1 Intelligent non-contact sensor switch;

2 Excellent anti-interference ability;

3 Small detection angle, nearly linear;

4 Compact size, easy to install, convenient to use;

5 Applications: Intelligent sensing sanitary ware, home security, etc.;

Specifications:

1 Power Supply: DC 12V;

2 Sensing Range: 2cm-100cm (adjustable, clockwise→further; anticlockwise→closer);

3 Sensing Angle: 10-15°(cone angle);

4 Sensing Type: Active;

5 Quiescent Current: <10uA;

6 Operation Current : <300mA;

7 Output Mode: Solenoid valve output ;

8 Indicator: Red indicator;

9 Working Temperature: -10-50°C;
