200kHZ High Frequency Ceramic Ultrasonic Sensor W/wire DetectorCeramic Ultrasonic SensorUltrasonic DetectorUltrasonic Transducer
US$ 13.51 - 20.33
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
DYP
Model Number:
DYP-200E18TR-X
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hot!200KHz Ultrasonic Transducer (waterproof Type)Aluminium Waterproof Utrasonic SensorUltrasonic Sensor for Web Guiding SystemUS$ 13.51 - 20.33MOQ: 1000 Pieces -
200KHz Aluminium Ultrasonic Sensor W/Wire DetectorDomestic High Precision Waterproof Ultrasonic SensorWeb Guiding System SensorsUS$ 13.51 - 20.33MOQ: 1000 Pieces
-
High Frequency(200KHz)Ultrasonic TransducerDomestic High Precision Ultrasonic SensorWeb Guiding Systems SensorsUltrasonic SensorUS$ 13.51 - 20.33MOQ: 1000 Pieces
-
400KHz Small High Power Ultrasonic TransducerTiny Ultrasonic Transducer for Short DistanceUltrasonic Sensor Web Guiding SystemUS$ 14.32 - 21.96MOQ: 500 Pieces
-
High Frequency(125KHz)ultrasonic SensorUltrasonic Range Measurement ModuleWaterproof Ultrasonic Sensor Distance Measuring ModuleUS$ 53.75 - 72.58MOQ: 10 Sets
Place of Origin
Guangdong, China
Brand Name
DYP
Model Number
DYP-200E18TR-X
Usage
Level Sensor
Theory
Ultrasonic Sensor
Output
Digital Sensor
DYP-200E18TR-X ultrasonic sensor provides non-contact distance measuring of 10cm to 2 meters range and with 3.5cm long wire detector. This ultrasonic sensor module measures 0.7 inch in diameter, 0.4inch high.
Specification:
| Model No. | DYP-200E18TR-X |
| Center Frequency | 200.0±8.0KHz |
| Bandwidth | 16KHz |
| Echo Sensitivity | -60dB/min |
| Parallel Resistance (Min.) | 600 Ohm ±30% |
| Capacitance | 400pF±20% |
| Max. Input Voltage (Pulse) | 500V |
| Directivity(-3dB) | 7°±2° |
| Distance of Detection | 0.1~2m |
| Operating Temperature Range | -20°C ~ +80°C |
| Storage Temperature Range | -35°C ~ +85°C |
| Total Size (Dia.x H) | Approx. 0.7 x 0.4 inch |
| Wire Length | Approx. 1.4 inch |
