CNC Hydraulic Plate Bending Machine
- 100 Set / Sets per Month
- shanghai
- T/T L/C D/P D/A Credit Card PayPal
- 10mm hot press brake bending machine for brake pad
- Custom bending press brake and shearing machine
- Square steel tube press brake machine for making gutters
- CNC hydraulic press brake steel bar cutting and bending machine
- Crank type bending machine heavy duty press brake 125t 3200
- 6 axes cnc press brake machine hydraulic for making gutters ceramic
Product Details
Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | YQ |
Model Number: | WC/E67Y/K | Machine Type: | Other, plate bending machine | Raw Material: | Pipe |
Material / Metal Processed: | Carbon Steel | Power: | Cnc | Automation: | Automatic |
Extra Services: | Welding / Brazing | Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Totally steel welding structure. Internal stress eliminated via vibration aging, with good strength and stability
Main Feature
1. Totally steel welding structure. Internal stress eliminated via vibration aging, with good strength and stability.
2. Rate of flow from servo proportional valve, and data from electronic meter, together control the sliders Y1&Y2 synchronous movement.
3.Slide repetition accuracy is 0.01mm, the bending angle is 0.5 º
4. Slider low and fast speed switch position and up limit stop position are sensed by grating ruler, and which feedback to computer and then adjust.
Specificaion:
Type | Nominal Pressue | Working table length(mm) | Distance withine standing columns(mm) | Open height(mm) | Throat depth(mm) | Backgauge range(mm) | Motpr power(mm) |
WC/E67Y/K-40T/2500 | 400 | 2500 | 2050 | 210 | 200 | 110 | 4 |
WC/E67Y/K-63T/2500 | 630 | 2500 | 2050 | 235 | 250 | 120 | 5.5 |
WC/E67Y/K-80T/2500 | 800 | 2500 | 2050 | 330 | 320 | 120 | 7.5 |
WC/E67Y/K-80T/3200 | 800 | 3200 | 2560 | 330 | 320 | 120 | 7.5 |
WC/E67Y/K-100T/2500 | 1000 | 2500 | 2050 | 330 | 320 | 120 | 7.5 |
WC/E67Y/K-100T/3200 | 1000 | 3200 | 2500 | 330 | 320 | 150 | 7.5 |
WC/E67Y/K-100T/4000 | 1000 | 4000 | 2960 | 400 | 320 | 120 | 7.5 |
WC/E67Y/K-125T/3200 | 1250 | 3200 | 2500 | 330 | 320 | 150 | 7.5 |
WC/E67Y/K-125T/4000 | 1250 | 2500 | 2960 | 330 | 320 | 120 | 7.5 |
WC/E67Y/K-160T/3200 | 1600 | 3200 | 2500 | 400 | 320 | 200 | 11 |
WC/E67Y/K-160T/4000 | 1600 | 400 | 2940 | 400 | 320 | 200 | 11 |
WC/E67Y/K-160T/6000 | 1600 | 600 | 4600 | 400 | 320 | 200 | 11 |
WC/E67Y/K-200T/3200 | 2000 | 3200 | 2500 | 435 | 300 | 200 | 15 |
WC/E67Y/K-200T/4000 | 2000 | 4000 | 3100 | 435 | 300 | 200 | 15 |
WC/E67Y/K-200T/6000 | 2000 | 6000 | 4800 | 435 | 320 | 200 | 15 |
WC/E67Y/K-250T/3200 | 2500 | 3200 | 2500 | 435 | 320 | 200 | 18.5 |
WC/E67Y/K-250T/4000 | 2500 | 4000 | 3100 | 435 | 320 | 200 | 18.5 |
WC/E67Y/K-250T/6000 | 2500 | 6000 | 4800 | 435 | 350 | 200 | 18.5 |
WC/E67Y/K-300T/3200 | 3000 | 3200 | 2600 | 435 | 350 | 200 | 22 |
WC/E67Y/K-300T/4000 | 3000 | 4000 | 3100 | 435 | 350 | 200 | 22 |
WC/E67Y/K-300T/6000 | 3000 | 6000 | 4800 | 435 | 350 | 200 | 22 |
equipment quality promise:
1, the Company's manufacturing facilities are applicable to the relevant national standards and enterprise standards.
2, the company's products are manufactured to meet the technical requirements and parameters should be listed in the specification and to ensure safety and reliability.
3, the company may send engineers to the demand-side participation to help guidance of installation and commissioning of equipment until the machine is qualified and can be put into use. Also we can help the demand side with training equipment operators and maintenance personnel. (Note: The installation and commissioning of equipment abroad, we will take cost in accordance with the cost of a standard international practice)
4 Equipment has 1 year warranty, during the warranty period, the company can track service and maintenance.
Our services:
1.Oversea engineers:
We provide oriented after-sales service including the oversea engineers tranning available and also international dealer center for any emergency guidance.We have established worldwide network to guarantee our timely response for your any demand no matter where you are.
2.Learning trip:
We welcome engineers from your side to learn the technical design and normal maintenance here, this will help you easyly to understanding.
3.English Manual:
We have Mannual to show you along with the machine.So you can learn this from the existing document to deeper your knowledge and understanding.
4.Face to face to teacing:
Through internet video face to face for machine teaching,because of the high development in internet,the world has become smaller and you can easy contact us if any assistance needed.
5.Through all the ways,we will guarantee the service quality and ensure you will be well helped anything anywhere.
Our company:
Jiangsu Yaoqiang Technical Group is a dealers holding type and high-tech enterprise. It mainly supply welding, cutting, milling, pipe producing production line as well as electrical automation equipment. The group consists of Jiangsu Silver Coast International Trading Development Co., Ltd (locate in Wuxi)& Dongtai Yaoqiang Mechinery Manufacture Co., Ltd. While Wuxi company, which is located in National technical industry park, i. e.The Wuxi Liando U Valley, besides the Taihu lake with beautiful scenery and renowned humanities, is mainly focus on enterprise blue print, R&D, marketing,trading, management
and finance. The Dongtai plant is devoted to technics, manufacture, process control, test and after-service, which locates at Dongtai Tangyang Xinhong Machinery industry park, in the wet land area off the seashore of Huanghai.
So we are manufacturer and trader. The Wuxi part is for trading and Dongtai part is forproducing.
If you are interested in this machine,please send E-mail to me or contact me directly!
