New Products Intellegent Lead Acid Battery Charger

New Products Intellegent Lead Acid Battery Charger photo-1
New Products Intellegent Lead Acid Battery Charger photo-2
New Products Intellegent Lead Acid Battery Charger photo-3
New Products Intellegent Lead Acid Battery Charger photo-4
New Products Intellegent Lead Acid Battery Charger photo-5
New Products Intellegent Lead Acid Battery Charger photo-6
US$ 17 - 21 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
LVXIANG
Model Number:
LX1206CSF
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name LVXIANG
Model Number LX1206CSF
Output Type Other, Electric
Connection Plug In
Product Description

 6V-12V 0-14.5A  intelligent lead-acid battery charger

      intelligent lead-acid battery charger is widely used on electric golf cart, sightseeing car,city car .it is a special design product, to meet charger requirement of power battery on the electric vehicle. It uses advanced soft-switch technique, and has features of small size, high efficiency, stability & reliability, and long life.

      Advanced and intelligent multi-section charging mode can avoid lack charging or over charging, and reduce water-lose phenomenon because of charging as far as possible, andavoid electrode board vulcanization because of lack charging, to extend battery life cycle greatly.







Product Effects

Technical Index



Input Voltage: AC100V~240V  50~60Hz





Full Load Efficiency: ≥88%



Ambient Temperature: -20℃~+40℃





Storage Temperature: -40°C~80°C



Certification: CE/UL/ROHS/FCC





  Product Specification





Battery voltage

Charge current



6V

7.5Vmax



12V

14.5Vmax



















     Protection and advantages



      Output short circuit: When accident output short circuit occurs, charger can limit output current, and can automatically recover when short circuit disappears.



      Over heatwhen inner temperature exceeds 65°C, charger begins to reduce output current automatically, temperature rises 5°C each, then output current reduces 6%. When inner temperature exceeds 90°C, charger stops, overheat LED lights.



      Battery reverse connection:When the output of charger is reverselybattery electrode, the charger never starts, and no output. When the connection is right, the charger can start to work automatically.



     Intelligent MCU power charging management:can recoganize the battery spec automatically andshift to the right battery spec needs,set up a shcedule depends on battery situation automatically



     Repair and protection function:can repair dead battery or old battery,if old battery or long time no use battery can not work,then our this model can repair it autimatically when connected and then can use it again; when full charge,will turn to maintnance mode automatically



     Multi current function:can shift to most suitable current according to battery when charging



      Appearance Design:meet the IPX-4 waterproof standard

Product Uses

Operation method



    Range of Use

1. This product can be only used with the lead acid battery, which was matching tested before. The detail can be acquired from distributor or factory.



    Operation Steps

1. Please place product in the situation of dry and clean, and good ventilation.

2. Check if the input voltage is correct, and confirm that the grounding is good.

3. Connect the charge output with battery, and be sure that the polarity is right. The fan runs, and begins to charge after self-checking.

4. Charger will turn to maintance mode after it finished charging, and display the status of full.



Packaging & Shipping

Packaging : Power adapter   with White paper box a carton



Delivery: 15 days after receiving the depositNew products intellegent lead acid battery charger

New products intellegent lead acid battery charger

Company Information

Shenzhen Lvxiang Technology Co,.Ltd  was found in 2010,we are manufacturer specialized in laptop adapter and ac dc power supply in 4 years .And dedicated to producing laptop adapter , 12v adapter , adapter 12v  ,universal laptop adapter , 5v 2a usb power adapter  ,12V desktop adapter for LED.AC DC power adapter ,wall adapter ,metal caese ,switching power supply for LED ,car charger , powerline adapter , ac power adapter , plug adapter, travel adapter , 60W 12V 4A car battery charger adapter /charger plate/tablet charger, power adapter  and so on New products intellegent lead acid battery chargerNew products intellegent lead acid battery charger

Detailed Images

Power supply

New products intellegent lead acid battery chargerNew products intellegent lead acid battery chargerNew products intellegent lead acid battery chargerNew products intellegent lead acid battery chargerNew products intellegent lead acid battery chargerNew products intellegent lead acid battery charger

Certifications

New products intellegent lead acid battery chargerNew products intellegent lead acid battery charger
