Alloy spray 38CrMoAlA PP PE plastic screw and barrel
Specification
Screw diameter: 30-360mm
Barrel diameter: 85-360mm
Mould Clamping Force: 250-32000KN
Shot Weight: 15-50000g
Screw can be mated with different head
Barrel can be mated with different nozzles
The compression ratio of the screw can be designed according to different products and mixtures
Technicl Parameter
| Base Material |
1)38CrMoAlA(JIS SACM645) 2)Cr12MOV(JIS SKD-11) 3)4Cr5MoSiV1(JIS SKD-61) 4)42CrMo(AISI 4140) 5)9Cr18MoV |
| Bimetallic Alloy Materials |
1)Fe-based alloy 2)Ni-based alloy/Deloro alloy 3)Co-based alloy 4)NiCo-based alloy 5)Tungsten carbide/Wolfram carbide |
| Bimetallic Alloy level |
Level A - containing Tungsten of 40% Level B - containing tungsten of 25% Level C - containing tungsten of 9.5% |
| Heat Treatment |
Nitriding treatment(>100 Hours) Hard Chrome Plating treatment Nickel alloy plating.treatment High-frequency quenching |
| Technology Parameter |
1)Depth of Nitrided Layer: 0.5-0.8 mm Hardness of Nitrided Layer: 950-1020Hv 2)Thickness of Hard Chrome Plating Layer: 0.03-0.08mm Hardness of Hard Chrome Plating Layer: ≥950HV 3) Bimetallic Barrel Centrifugal Casting (Inlay Alloy) Bimetallic Screw: Plasma Alloy Coating Spraying Depth of Bimetallic Layer: >2mm Hardness of Bimetallic Layer: HRC58°-62° |
| Basic Information |
Nitrided Brittleness:Less Than Grade 1 Surface Roughness:Ra 0.4um Screw Straightness:0.015mm |
| Material Application |
1)General Plastics 2)ABS,PA,PC,PE,PET,PP,PS,EVA,PU,PVC,U-PVC,etc 3)PA + GF(Glass Fiber) 4)Flame-resistant Reinforced Plastics 5)Modified Engineering Plastics 6)All kinds of Mixed Recycled Material(in Scrap or Granule),etc |
Other Information
1) Name: Bimetallic screw & barrel for plastic machine
2) Lead Time: About 20 to 25 working days after we receive the deposit
3) Packaging Detail: Film wrapped in wooden case without fumigation (export standard) But can be customized according to customer requirements
4) Means of transport: Ocean, Air, Express
5) Long lifetime,low energy consumption.
6) Wonderful plasticizing
7) High wear resistance, resistance to corrosion
8) Fast and On time delivery
Product Flow
Blanking ----> Rough Machining ----> Quenching & Tempering ----> Semi Finishing Machining ----> Finish Machining ---> Nitriding or Bimetallic Processed ---> Detecting Finished Product ---> Packing & Shipping
Bimetallic screw & barrel picture
Jinsheng Bimetallic Plastic Machinery Factory was established in 2004. It was developed as a large-scale and comprehensive company specializing in manufacturing the kinds of Screws and Barrels in Zhoushan.such as bimetallic barrel & screw ,conical twin screws & barrels ,parallel twin screws & barrels,single screw &barrel , rubber screw & barrel ,planetary screw & barrel and components apply for injection molding machine and extruder machine .
For the material of screw and barrel we usually used: #45 steel,40Cr,38CRMOALA, 42CrMo,SKD11,SKD61 and high temperture ALLOY etc.
Jinsheng team aim at providing the best services to customers which include providing short lead time, best price and best after sales services. These allow us to create good relationship with customer. Moreover, our engineering department can design special screw and barrel design for some special plastic material such as HDPE, LDPE. This special design can provide high output with low energy consumption. With our great effort on product quality and services, we win a lot of support from different customers which from machinery and plastics field. we will make improvement continuously so as to win customer support from different countries.
To our old customer’s help and continuous support,we thank you.
To our new customers,we give you our warmest welcome.
Packing
1.screw and barrel are coated with a layer of oil.
2.screw and barrel are wrapped in a layer of plastic film.
3.screw and barrel are fixed in strong wooden case.
4.Volume for one set of screw and barrel is about 0.5cubic meter -5 cubic meter
Shipping
Means of transport: Ocean, Air, Express,we can operate by customer request.
Jinsheng Services and Advantage:
1) Jinsheng have more than 1 year quarantee
2) Jinsheng have over 10 years history
3) Jinsheng have a strong work-hard team
4) Jinsheng is the first factory to make the bimetallic screw and barrel
5) Jinsheng will handle all difficult for products
6) Jinsheng will meet customer request
7) Jinsheng will be keeping improving
What is Jinsheng company CULTURE?
Management idea : confidence determination
Working Spirit :Responsibility,improvement
Positioning :stability,development, international
Jinsheng Export to
Due to our high quality products and outstanding customer service, we have gained a global sales network reaching America, Germany, Brazil, Russia, Ukraine, India, Pakistan,Egpyt,Argentina and some other countries and regions.
