Recycling Granulator Screw Barrel for HDPE PVC PP PE Extruder Machine

Recycling Granulator Screw Barrel for HDPE PVC PP PE Extruder Machine thumbnail-1
Recycling Granulator Screw Barrel for HDPE PVC PP PE Extruder Machine photo-1
US$ 800 - 21,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
JS ALLOY
Model Number:
JS-blowing screw barrel
Contact Supplier Request Quote Chat Now
Zhoushan Dinghai Jinsheng Bimetallic Plastic Machinery Factory (General Partners)
Payment & Shipping
Payment Methods:
Port of Shipment:
ANY CHINA PORT
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name JS ALLOY
Model Number JS-blowing screw barrel

Topic:  Recycling Granulator Screw Barrel for HDPE PVC PP PE Extruder Machine



Product Description



Specification

Screw diameter: Ø15-Ø360

L/D=15-45

Screw structure and compression ratio can be designed according to different products and raw material.



Our company have many twin screw barrel designs of world-famous brand: such as CINCINNATI,BATTENFELD,KRUSSMAFFEI,BAUSANO,WEBER,AMUT....





Surface Treatment

1) Heat Treatment

2) High Frequency Treatment

3) Nitriding treatment

4) Hard Chrome Plating treatment

5) alloy plating treatment



Technical Date



Depth of nitration case:0.5-0.8mm
Hardness of nitration:HV950-1020
Roughness of the surface:Ra 0.4um

Screw straightness: 0.015mm/m
thickness of double alloys: 2-3mm

Hardness of double alloys:HRC58-62
Suitable plastic material: PP,PE,ABS,AS,PS etc.
Material: 38CrMoALA





Application



Material Application



Scope: WPC PVC ,WPC PE ,Super high molecular sheet ,1/2 high calcium buckle, 50-400 high Calcium pipe ,50-300 high Calcium Profile , Soft PVC sheet , XPS-PVC ,PP ,PE, ABS, PVC, Raw material , pelletzing ,Pipe, Profile, Sheet etc





Recycling Granulator Screw Barrel for HDPE PVC PP PE Extruder Machine



Application Machine



Recycling Granulator Screw Barrel for HDPE PVC PP PE Extruder Machine





Single screw and barrel picture show


Recycling Granulator Screw Barrel for HDPE PVC PP PE Extruder Machine
Recycling Granulator Screw Barrel for HDPE PVC PP PE Extruder Machine
Recycling Granulator Screw Barrel for HDPE PVC PP PE Extruder Machine







Products Inspect Show:

Recycling Granulator Screw Barrel for HDPE PVC PP PE Extruder Machine



Workingshop Show:

Recycling Granulator Screw Barrel for HDPE PVC PP PE Extruder MachineRecycling Granulator Screw Barrel for HDPE PVC PP PE Extruder Machine



Packaging & Shipping



1) Woode case package
2) Plastic film pakage
3) As buyer request

4) Ship to Ningbo port or Shanghai Port

5) Deliver time: within 20 working days after confirmed with buyer

 Recycling Granulator Screw Barrel for HDPE PVC PP PE Extruder Machine



Our Services

Services

1) Jinsheng have more than 1 year quarantee

2) Jinsheng have over 10 years history
3) Jinsheng have a strong work-hard team
4) Jinsheng is the first factory to make the bimetallic screw and barrel
5) Jinsheng will handle all difficult for products
6) Jinsheng will meet customer request
7) Jinsheng will be keeping improving



 Jinsheng also product other items:



1) BIMETALLIC SCREW BARREL

2) INJECTION SCREW BARREL

3) EXTRUDER SCREW BARREL

4) CONICAL TWIN SCREW BARREL

5) PARALLEL TWIN SCREW BARREL

6) RUBBER SCREW BARREL

7) PLANETARY SCREW BARREL

8) COMPONENTS



Recycling Granulator Screw Barrel for HDPE PVC PP PE Extruder MachineRecycling Granulator Screw Barrel for HDPE PVC PP PE Extruder MachineRecycling Granulator Screw Barrel for HDPE PVC PP PE Extruder Machine





Company Information

Jinsheng Bimetallic Plastic Machinery Factory is manufacturing Screws and Barrels Jinsheng have over 10 years history.





1.We are a professional company specialized in manufacturing many types of screw, the barrel can be applied on all types of injection moulding machine,rubber hot-feeding extruder, rubber cold-feeding extruder, pin barrel cold feed extruder, plastic extruder with different specifications.




2.The models of screw include:
Variable pitch and variable depth, variable pitch and equal depth, variable depth and equal pitch, and equal depth and pitch.
Groove multi-die type, composite type, mixing type and separating type.




3. The material of screw: manufactured with high-quality nitro alloy steel, applying the method of hardening and tempering and nitriding, thus it enjoys the characteristics of long working life, wear resistance, and anti corrosion. Besides, the technique of hard alloy spraying or chrome plating can be used on the working surface of screw, which will make it have better using effectiveness.



 Recycling Granulator Screw Barrel for HDPE PVC PP PE Extruder Machine

FAQ



Why used 38CrMoAlA material for screw and barrel ?



 38CrMoAlA and #45 Steel difference:



  • 38CrMoAlA is alloy structural  steel
  • 38CrMoAlA is a kind of special nitrided steel, it need hardening & tempering before nitrided, and hardness is more than HV900, 0.3mm-0.8mm thickness.
  • 45# is Carbon  structural  steel
  • 38CrMoAlA main advantage is wear-resistance, it is harder than 45#.



38CrMoAlA

42CrMo

4Cr5MoSiV1 (SKD61)

Cr12MoV (SKD11)

C: 0.35~0.42%

Si:0.20~0.45%

Mn:0.30~0.60%

Cr:1.35~1.65%

Mo:0.15~0.25%

Al:0.71.~1%

C :0.38~0.45%

Si:0.17~0.37%

Mn:0.50~0.80%

S :≤0.035%

P :≤0.035%

Cr:0.90~1.20%

Ni:≤0.030%

Cu:≤0.030%

Mo:0.15~0.25%

C: 0.32-0.42%

Si: 0.80-1.20%

Mn:0.20-0.50%

Cr: 4.75-5.50%

Mo: 1.10-1.75%

Ni: -

V: 0.80-1.20%

C :1.45~1.70%

Si:≤0.40%

Mn:≤0.40%

S :≤0.030%

P :≤0.030%

Cr:11.00~12.50%

Ni:≤0.25%

Cu:≤0.30%

V :0.15~0.30%

Mo:0.40~0.60%
