Product Name: Single Bimetallic Screw Barrel For Extruder machine
Screw tpye: commom type, gradual type, sudden type, barrier type, pinned type, exhaustive type, separate type, granulation type, wave type ect.
Screw Diameter: Φ15-Φ360
L/D=15-45
Screw structure and compression ratio can be designed according to different products and raw material.
Base Material
1)38CrMoAlA(JIS SACM645)
2)Cr12MOV(JIS SKD-11)
3)4Cr5MoSiV1(JIS SKD-61)
4)42CrMo(AISI 4140)
5)9Cr18MoV
Technical Parameter
| Depth of nitration | 0.5-0.8mm |
| Hardness of nitration | 950-1020HV |
| Straight of screw | 0.015MM |
| Fragility of nitration | Less than grade 1 |
| Roughness of surface | Ra 0.4um |
| Depth of alloy layer | 2-3mm |
| Hardness of alloy | HRC58-62 |
| Hardness after hardening and tempering | HB260-290 |
| Hard chrome plating thickness | 0.03-0.08mm |
| Hardness of hard chrome plating | ≥950HV |
Picture for Bimetallic Screw Barrel Extruder
Material Application
1)General Plastics
2)ABS,PA,PC,PE,PET,PP,PS,EVA,PU,PVC,U-PVC,etc
3)PA + GF(Glass Fiber)
4)Flame-resistant Reinforced Plastics
5)Modified Engineering Plastics
6)All kinds of Mixed Recycled Material(in Scrap or Granule),etc
Working Shop:
Jinsheng with strong working hard team,with advanced production facilities and qualified technicians and senior managers.
Packing
1.screw and barrel are coated with a layer of oil.
2.screw and barrel are wrapped in a layer of plastic film.
3.screw and barrel are fixed in strong wooden case.
4.Volume for one set of screw and barrel is about 0.5cubic meter -5 cubic meter
Shipping
Means of transport: Ocean, Air, Express,we can operate by customer request.
What is Jinsheng company CULTURE?
Management idea : confidence determination
Working Spirit :Responsibility,improvement
Positioning :stability,development, international
Jinsheng Advantage:
1) With high wear resistance and anti-corrosion
2) Through processing ,it can be prolong use life for screw and barrel
3) Cold and heat spraying for hard metal process
4) High-frequency quenching technology
5) Advanced nitriding technology
6) Processing and manufacturing process for Bimetallic
7) Lowest price, high quality, delivery on time
Jinsheng Bimetallic Plastic Machnery Factory was established in 2004. It was developed as a large-scale and comprehensive company specializing in manufacturing the kinds of Screws and Barrels in Zhoushan.such as bimetallic barrel & screw ,conical twin screws & barrels ,parallel twin screws & barrels,single screw &barrel , rubber screw & barrel ,planetary screw & barrel and components apply for injection molding machine and extruder machine .
Exhibition Show:
Jinsheng Export to :
Due to our high quality products and outstanding customer service, we have gained a global sales network reaching America, Germany, Brazil, Russia, Ukraine, India, Pakistan,Egpyt,Argentina and some other countries and regions.
If you have any quotation, please contact with me .we will reply to you as soon as possible
Company Name: Jinsheng Bimetallic Plastic Machinery Factory
1) Contact Person: Vicky
2) Tel/Fax: 86-580-8043200/86-580-8043198
3) Mobile: 86-136-4680-7378
4) E-mai: may@js-screws com
5) Skype: may_3848
6) Website:
7) Alibaba: www.jinshengalloy.en.china.cn
8) TradeManager: cn1511247190
Add:6 Liuhang Road, Xihou Industry Zone, Jintang Town,Dinghai District, Zhoushan City, Zhejiang Province,306031
Jinsheng welcome you visit our factory and supply the valueable suggestion!!!
