Home > Products > Rubber Screw and Barrel > Screw Barrel/ Rubber Machine/MANUFACTURER/JINSHENG
Screw Barrel/ Rubber Machine/MANUFACTURER/JINSHENG
- SHANGHAI/NINGBO
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
JINSHENG/2016 Screw Barrel for Rubber Machine
-
High Quality Screw Barrel for Rubber Extruder With High Quality
-
Supply Plastic Extruding Parts Planetary Screw Barrel
-
2016 Planet Screw And Barrel/planetary Screw Barrel for Extrusion
-
Pvc Planetary Roller Extruder Screw Barrel
-
Planetary Screw And Barrel for Large Extruder Machine
Product Details
| Place of Origin | Zhejiang, China | Brand Name | JS-ALLOY | |
| Model Number | JS-S |
Product Description
Product Name:Extrusion RUBBER MACHINE
Type: OD18-250MM
Injection size:15-50000g
We can provide different size screw head and sprinkler head
Base Material
1)38CrMoAlA(JIS SACM645)
2)Cr12MOV(JIS SKD-11)
3)4Cr5MoSiV1(JIS SKD-61)
4)42CrMo(AISI 4140)
5)9Cr18MoV
Technical Parameter |
| Steel Material | DIN 41CrA1Mo7 / AST M4140 / GB 38CrMoAlA |
| Deepness of Nitriding Layer | 0.7 mm -0.9 mm |
| Hardness of Nitriding | HV900 - HV1,000 |
| Nitriding Brittleness | ≤Grade 1 |
| Chromate plating | Thickness 0.05 mm - 0.10 mm, hardness HV950 |
| Special treatment | Carbide coating on screw flight and bimetallic barrel |
| Screw straight tolerance | 0.015 mm/m |
| Surface roughness | Ra 0.4μm |
|
Material Application
1)General Plastics
2)ABS,PA,PC,PE,PET,PP,PS,EVA,PU,PVC,U-PVC,etc
3)PA + GF(Glass Fiber)
4)Flame-resistant Reinforced Plastics
5)Modified Engineering Plastics
6)All kinds of Mixed Recycled Material(in Scrap or Granule),etc
Working Shop:
Jinsheng with strong working hard team,with advanced production facilities and qualified technicians and senior managers.
1) Wooden case package
2) Plastic film package
3) As buyer request
Jinsheng Bimetallic Plastic Machnery Factory was established in 2004. It was developed as a large-scale and comprehensive company specializing in manufacturing the kinds of Screws and Barrels in Zhoushan.such as bimetallic barrel & screw ,conical twin screws & barrels ,parallel twin screws & barrels,single screw &barrel , rubber screw & barrel ,planetary screw & barrel and components apply for injection molding machine and extruder machine .
Contact information:
Zhoushan Dinghai Jinsheng Bimetallic Plastic Machinery Factory
Add:6 Liuhang Road, Xihou Industry Zone, Jintang Town, Dinghai District,Zhoushan City,Zhejiang Province,316031
TEL:86-580-8043200 FAX:86-580-8043198
MOBILE:86-13646807378 SKYPE:may_3848
ALIBABA:ZSJINSHENG
Contact Us
- Zhoushan Dinghai Jinsheng Bimetallic Plastic Machinery Factory (General Partners)
- Contact nameHAPPY TU Chat Now
- Phone86-580-8043200
- AddressNo6 LiuHang Road,XiHou Industry Zone,jintang Town ,zhoushan city, Zhoushan, Zhejiang
