Double end tenoenr
I. Description
This double end tenoner is suitable to process the cutting and grooving in flooring, doors, furniture etc fields. The machine base is processed in large CNC machine. Two high precision linear orbits are assembled to assure the stable movement as well. To keep good performance, machine is widened by servo motor system. All the electric components are adopted international brands to assure stable and excellence performance.
II. Specification:
1. Working length(mm): 250-3000
2. Working thickness(mm):6-80
3. OD for tools(mm)
Scoring saw: dia 160
Cut-off saw: dia 300
Milling cutter: dia 125-180
4. ID for tools(mm)
Scoring saw: dia 25.4
Cut-off saw: dia 35
Milling cutter: dia 40
5. Motor power(kw)
Scoring saw: 2.2
Cut-off saw: 4
Milling cutter: 5.5
Total motor power: 27.5kw
6. Speed
Feeding speed: 5-25(m/min)
Milling cutter speed: 8000r/min
Cut-off saw speed: 3000r/min
7. Weight: 5.6T
8. Size(L*W*H)(mm): 4880*3300*1800
III. Advantage
1. Electrical movement for the pressure belt with the pneumatic locked and controlled by digital positioner.
2. Machine base is over 1300mm width with high precision linear orbits and with steel dusty proof to protect the orbits.
3. High precision lightweight convey belt is assembled with bearings. High feeding speed and less noise, it is suitable for high speed precessing.
4. With the special location locked system and the little fence against the work pieces just with the surface, it will not leave pressed mark in the work pieces.
