Specifications
manufacturer 30W led driver for floorlightled power driver
constant voltage of constant voltage led power supply
more module
manufacturer 30W led driver for floorlight
30W led power supply
led power driver
constant voltage of constant voltage led power supply
Applications]
LED Signage / Channel Letter
LED Architectural Lighting
LED Commercial Industrial Lighting
LED General Luminaire
[Features]
Available Constant Current, or Constant Voltage
Suitable For Dry, Damp Locations, Meet IP66.
Convection Cooled in Plastic Housing.
RoHS Compliant.
Three Years Warranty.
[Specifications]
AC input range | 90-264Vac/ 0.5A /50-60Hz | Operation temp | -30°C - +50°C,Tc:90°C |
Input inrush current | <10A/110Vac <20A/230Vac | Storage temp | -40°C - +85°C |
Power factor | >0.95 at full load,115Vac/230Vac | Safety | UL1310 Class 2. CE. CCC |
Efficiency | 85% Typical | Dimension | L115*W45*H30 |
Protection | OCP. OVP. SCP-Auto recovery | Weight | 142g Typical |
[Model Listing]
CONSTANT CURRENT | CONSTANT VOITAGE | ||||||
MODEL | Vo | Io | W | MODEL | Vo | Io | W |
UTL-30W3063V330A | 30-63V | 330mA | 30W | UTL-30W48V625A | 48V | 625mA | 30W |
UTL-30W2652V650A | 26-52V | 650mA | `30W | UTL-30W36V833A | 36V | 833mA | `30W |
UTL-30W1836V680A | 18-36V | 680mA | 30W | UTL-30W24V1250A | 24V | 1250mA | 30W |
UTL-30W1224V1110A | 12-24V | 1110mA | 30W | UTL-30W12V2500A | 12V | 2500mA | 30W |
factory
product picture
About us:
We supply LED power,switching power supply and AC/DC Adapter with good quality and very competitive price. Hope to be a partner of your company! If you are interesting in it ,pls contact with us
