SINOTRUK HOWO Heavy Truck Parts Gearbox HW19710

Name: SINOTRUK HOWO Heavy Truck Parts Gearbox HW19710
Brand: Sinotruk
SKU: 129117545
Availability: InStock

US$ 2,100 - 3,600 MOQ: 1 Unit

Key Specifications

Type:

Gear Box

Truck Model:

Other, sinotruck

Size:

900*800*500mm

Liuzhou Joyhood Trading Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qindao Port Guangzhou Port Shanghai Port

Delivery Detail:

Delivery time depends on order quantity.

Type Gear Box

Truck Model Other, sinotruck

Size 900*800*500mm

OEM No. HW19710090402

Brand Name Sinotruk

Model Number HW19710

Product Description

SPECIFICATIONS FOR HW19710 TRANSMISSION

Transmissiom Model	HW19710	Installation Length		843
Type	10 forward gears, 1 reverse gear (Three section shell)
Max Input Torque	1900N.m	Maximum Output Speed		2600rpm
Gearbox Ratios	Gears	Speed Ratio	Gears	Speed Ratio
	1	14.28	6	3.26
	2	10.62	7	2.43
	3	7.87	8	1.80
	4	5.87	9	1.34
	5	4.375	10	1
	Reverse Gear		13.91
Lubrication	Splash lubrication of main tank, forced lubrication of secondary tank
Lubricant Grade	85W/90GL-4 or 85W/90GL-5
Fuel Quantity	12L (12.5L if including the PTO)

1)Main tank adopts twin-layshaft configuration, secondary tank adpots planetary transmission structure, improve assembly reliability.

2) Shell adopts vertical subdivision structure, easy to assembly and maintenance.

3) Samll cover design to make the structure more compact

4) Adpot active lubrication can adapt large slope working condition

Our Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery

Packaging
Size	1000(L) * 1000(W) * 600 (D)
Weight	450kg
Packaging Details	The normal package is plywood box(Size: LWH).If container is too tigher,we will use pe film for packing or pack it according to customers special request.
